Panasonic LUMIX DMC-G7 Basic Operating Instructions

Others
56
SQT0919 (ENG)
∫ General tips for using a Wi-Fi connection
•
Use within the communication range of the device to be connected.
• Is any device, such as microwave oven, cordless phone, etc., that uses 2.4 GHz frequency
operated nearby?
> Radio waves may get interrupted when used simultaneously. Use them sufficiently away
from the device.
• When the battery indicator is flashing red, the connection with other equipment may not start or
the connection may be disrupted.
(A message such as [Communication error] is displayed.)
• If you place the camera on a metal table or shelf, the radio waves may be adversely affected. In
such cases, you may not be able to establish a connection. Move the camera away from the
metal surface.
∫ About a wireless access point
•
Check if the wireless access point to connect is in operating state.
• The camera may not display or connect to a wireless access point depending on the radio
wave condition.
> Move this unit closer to the wireless access point.
> Remove the obstacles between this unit and the wireless access point.
> Change the direction of this unit.
> Change the location and orientation of the wireless access point.
> Perform the [Manual Input].
• It may not display even if the radio waves exist depending on the setting of the wireless access
point.
> Check the settings of the wireless access point.
> When the network SSID of the wireless access point is set not to broadcast, the wireless
access point may not be detected. Enter the network SSID to start the connection or enable
the SSID broadcast of the wireless access point.
• Connection types and security setting methods are different depending on the wireless access
point. (Refer to the operating instructions of the wireless access point.)
• Is the 5 GHz/2.4 GHz switchable wireless access point connected to other equipment using the
5 GHz band?
> The use of a wireless access point that can use 5 GHz/2.4 GHz simultaneously is
recommended. It cannot be used simultaneously with this camera if it is not compatible.
A Wi-Fi connection cannot be established.
Radio waves get disconnected.
Wireless access point is not displayed.
DMC-G7KHWbody_GN-SQT0919_eng.book 56 ページ ２０１５年５月２８日 木曜日 午後２時３８分

Panasonic LUMIX DMC-G7 Specifications

General

Megapixel	16.00 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size	52 mm
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/25 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Flash range (wide)	- m
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	77.4 mm
Width	124.9 mm
Height	86.2 mm
Weight	360 g
Weight (including battery)	410 g
