57
Others
(ENG) SQT0919
When the firewall of the OS, security software, etc. is enabled, connecting to the PC may not
be possible.
Some OS versions, including Windows 8, use two types of accounts: a local account and a
Microsoft account.
> Be sure to use the user name and password for the local account.
If you haven’t set up a local account, please create one.
The default workgroup name is set to “WORKGROUP”. If you changed the workgroup name,
the PC will not be recognised.
In [Change Workgroup Name] in [PC Connection] of the [Wi-Fi Setup] menu, change the
workgroup name to that of the PC you are connecting to.
Please confirm login name and password are correctly typed.
When the system time of Mac computer or Windows PC connected to a camera differs severely
from that of the camera, the camera cannot be connected to the computer or PC in some OSs.
> Please confirm [Clock Set] and [World Time] of the camera matches with time, date and
time zone in Windows PC or Mac computer. When both settings do not match severely,
please match them.
Image cannot be transmitted when the battery indicator is flashing red.
Is the size of the image too large?
> Reduce the image size at [Size], and then send.
> Transmit after dividing the motion picture with [Video Divide].
File format of the motion picture that can be sent differs depending on the destination.
Capacity or number of images in the web service is full.
> Login to “LUMIX CLUB”, and check the status of the destination on the web service link
settings.
Images cannot be transmitted to a PC.
When I try to set up a Wi-Fi connection with a Windows 8 PC, my user name and
password are not recognised, so I cannot connect to the PC.
The PC is not recognised when I use a Wi-Fi connection. The camera cannot be
connected to PC via Wi-Fi connection.
Transmission of the image fails midway. Some images cannot be transmitted.
DMC-G7KHWbody_GN-SQT0919_eng.book 57 ージ 2015年5月28日 木曜日 午後2時38分

Table of Contents

Other manuals for Panasonic LUMIX DMC-G7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-G7 and is the answer not in the manual?

Panasonic LUMIX DMC-G7 Specifications

General IconGeneral
Megapixel16.00 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size52 mm
Optical zoom- x
Focal length range14 - 42 mm
Maximum aperture number22
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/25 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Flash range (wide)- m
Flash exposure correction±3EV (1/2; 1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsNegative film, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)No
Self-timer delay2, 10 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)360 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth77.4 mm
Width124.9 mm
Height86.2 mm
Weight360 g
Weight (including battery)410 g
