1. Before Use
1
Focus distance reference mark (P168)
2
Status indicator (P41)/
Wi-Fi
®
connection lamp (P291)
• The lamp lights green when the camera is
turned on, and lights blue when it is
connected to Wi-Fi.
3
Camera ON/OFF switch (P41)
4
Motion picture button (P242)
5
[ ] (Exposure Compensation) button
(P173)/[Fn1] button (P70)
6
Function button (Fn11) (P70)
7
Rear dial (P47)
8
Shutter button (P44)
9
Front dial (P47)
10
Self-timer indicator (P201)/
AF Assist Lamp (P163)
11
Mode dial (P46)
• Rotate the mode dial to switch the Recording
Mode.
12
Flash (P230)
13
Hot shoe (Hot shoe cover) (P360)
• Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
14
Stereo microphone (P255)
• Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
15
Diopter adjustment dial (P42)
16
Drive mode dial
Single (P181):
Burst (P182):
4K Photo (P185):
Auto Bracket (P199):
Self-timer (P201):
Time Lapse/Animation (P204, 206):
17
[MIC] socket (P362)
• An external microphone (optional) can
record higher quality audio than the built-in
microphone.
18
Shoulder strap eyelet (P23)
19
Lens release button (P37)
20
Lens lock pin
21
Mount
22
Sensor
23
Lens fitting mark (P36)
To Next Page
