1
Focus distance reference mark
2
Status indicator (P13)/
Wi-Fi
®
connection lamp (P49)
3
Camera ON/OFF switch (P13)
4
Motion picture button (P36)
5
[ ] (Exposure Compensation) button/[Fn1]
button (P23)
6
Function button (Fn11) (P23)
7
Rear dial (P19)
8
Shutter button (P15)
9
Front dial (P19)
10
Self-timer indicator/
AF Assist Lamp
11
Mode dial (P20)
12
Flash
13
Hot shoe (Hot shoe cover)
• Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
14
Stereo microphone
• Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
15
Flash open lever
• The flash opens, and recording with the flash
becomes possible.
16
Diopter adjustment dial (P13)
17
Drive mode dial (P27)
18
[MIC] socket
19
[REMOTE] socket
20
USB socket
21
[HDMI] socket
22
Shoulder strap eyelet (P10)
23
Lens release button (P12)
24
Lens lock pin
25
Mount
26
Sensor
27
Lens fitting mark (P12)
