VQT4F91 (ENG)
12
Names and Functions of Components
∫ Camera body
1 Sensor
2Flash
3 Self-timer indicator/
AF Assist Lamp
4 Lens fitting mark
5 Mount
6 Lens lock pin
7 Lens release button
8 Flash open button
9 Touch screen/LCD monitor
10 Playback button
11 [Q.MENU/Fn1] button/
Delete/Return button
12 [MENU/SET] button
13 Control dial
14 Cursor buttons
3/Exposure Compensation button
1/WB (White Balance)
2/AF Mode button
4/[Drive Mode] button
This button in picture record mode will allow the
user to select between the following options.
Single/Burst/Auto bracket/Self-timer
15 [DISP.] button
8
910 1511
1213 14
