DMC-GX1EG-S vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
## VEP56158B MAIN P.C.B. 1 (RTL) E.S.D. EG,EC,EF,EB ## VEP58171A FLASH P.C.B. (RTL) [PAVCSG] E.S.D.
## VEP56158A MAIN P.C.B. 1 (RTL) E.S.D. PP,PC,EE,GC,
GH,GT,GK,GN,GD C8501 F1K2J223A029 C.CAPACITOR 630V 0.022U 1 [PAVCSG]
## VEP50100A TOP P.C.B. 1 (RTL) [PAVCSG] E.S.D. C8502 F1K2J333A029 C.CAPACITOR 630V 0.033U 1 [PAVCSG]
## VEP58171A FLASH P.C.B. 1 (RTL) [PAVCSG] E.S.D. C8503 F1K2J102A028 C.CAPACITOR 630V 1000P 1 [PAVCSG]
## VEP59109A EX LVF P.C.B. 1 (RTL) [PAVCSG] C8505 F1H0J1050012 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG]
 ## VEK0S31 CAPACITOR P.C.B. UNIT 1 [PAVCSG] C8506 F1J1A106A024 C.CAPACITOR CH 10V 10U 1 [PAVCSG]
D8501 B0ECGP000006 DIODE 1 [PAVCSG] E.S.D.
D8502 B0EDAT000002 DIODE 1 [PAVCSG] E.S.D.
## VEP50100A TOP P.C.B. (RTL) [PAVCSG] E.S.D.
 F8501 ERBRE1R50V FUSE 32V 1.5A 1 [PAVCSG]
C8002 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 [PAVCSG]
C8004 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 [PAVCSG] FP8501 K1MN10BA0108 CONNECTOR 10P 1 [PAVCSG]
C8005 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG] FP8502 K1MY04BA0370 CONNECTOR 4P 1 [PAVCSG]
C8007 F1G1E102A086 C.CAPACITOR CH 25V 1000P 1 [PAVCSG]
C8008 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG] IC8501 C0ZBZ0000914 IC 1 [PAVCSG] E.S.D.
C8009 F1G1C1030008 C.CAPACITOR CH 16V 0.01U 1 [PAVCSG]
C8093 F3E0J106A009 E.CAPACITOR CH 6.3V 22U 1 [PAVCSG] P8502 K1KA02ZA0001 CONNECTOR 2P 1 [PAVCSG]
D8001 B3AEB0000141 DIODE 1 [PAVCSG] E.S.D. Q8501 B1JBLP000022 TRANSISTOR 1 [PAVCSG] E.S.D.
D8002 B2ABDR000010 DIODE 1 [PAVCSG] E.S.D. Q8502 B1DFCG000020 TRANSISTOR 1 [PAVCSG] E.S.D.
D8003 B0BC8R2A0266 DIODE 1 [PAVCSG] E.S.D.
D8004 B3ABB0000150 DIODE 1 [PAVCSG] E.S.D. R8501 ERJ8GEYJ105V M.RESISTOR CH 1/4W 1M 1 [PAVCSG]
R8502 ERJ2GEJ104X M.RESISTOR CH 1/16W 100K 1 [PAVCSG]
 F8001 ERBRE2R50V FUSE 32V 2.5A 1 [PAVCSG] R8503 ERJ3GEYJ111V M.RESISTOR CH 1/10W 110 1 [PAVCSG]
R8505 ERJ8GEYJ105V M.RESISTOR CH 1/4W 1M 1 [PAVCSG]
FP8001 K1MY45BA0235 CONNECTOR 45P 1 [PAVCSG] R8506 ERJ6RED105V M.RESISTOR CH 1/10W 1M 1 [PAVCSG]
FP8002 K1MN04BA0208 CONNECTOR 4P 1 [PAVCSG] R8507 ERJ6RED105V M.RESISTOR CH 1/10W 1M 1 [PAVCSG]
FP8003 K1MY08BA0370 CONNECTOR 8P 1 [PAVCSG] R8508 ERJ2RHD153X M.RESISTOR CH 1/16W 15K 1 [PAVCSG]
FP8004 K1MY04BA0370 CONNECTOR 4P 1 [PAVCSG] R8509 ERJ2GEJ153X M.RESISTOR CH 1/10W 15K 1 [PAVCSG]
FP8005 K1MY04BA0370 CONNECTOR 4P 1 [PAVCSG] R8510 ERJ2GEJ560X M.RESISTOR CH 1/10W 56 1 [PAVCSG]
R8511 ERJ8GEYJ472V M.RESISTOR CH 1/4W 4.7K 1 [PAVCSG]
LB8001 J0JGC0000038 FILTER 1 [PAVCSG]
S8501 ESE18R62DXFD SWITCH 1 [PAVCSG]
P8001 K4ZZ04000057 CONNECTOR 4P 1 [PAVCSG]
T8501 G5D1A0000066 TRANSFORMER 1 [PAVCSG]
Q8001 B1ABDF000017 TRANSISTOR 1 [PAVCSG] E.S.D.
Q8002 B1CFHC000005 TRANSISTOR 1 [PAVCSG] E.S.D.
Q8003 B1ABDF000017 TRANSISTOR 1 [PAVCSG] E.S.D.
Q8004 B1ABCF000103 TRANSISTOR 1 [PAVCSG] E.S.D. ## VEP59109A EX LVF P.C.B. (RTL) [PAVCSG]
QR8001 B1GBCFJJ0064 TRANSISTOR-RESISTOR 1 [PAVCSG] E.S.D. FP7901 K1MY41BA0235 CONNECTOR 41P 1 [PAVCSG]
QR8002 B1GBCFJJ0064 TRANSISTOR-RESISTOR 1 [PAVCSG] E.S.D. FP7902 K1FY245E0001 CONNECTOR 45P 1 [PAVCSG]
R8001 ERJ2GEJ103X M.RESISTOR CH 1/10W 10K 1 [PAVCSG] R7900 ERJ2GEJ472X M.RESISTOR CH 1/16W 4.7K 1 [PAVCSG]
R8002 ERJ2GEJ223X M.RESISTOR CH 1/16W 22K 1 [PAVCSG] R7902 ERJ2GEJ680X M.RESISTOR CH 1/16W 68 1 [PAVCSG]
R8003 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R8004 ERA3YKD104V M.RESISTOR 1/16W 100K 1 [PAVCSG] RX7901 D1H8R0040009 RESISTOR NETWORKS 1 [PAVCSG]
R8005 ERJ2GEJ223X M.RESISTOR CH 1/16W 22K 1 [PAVCSG] RX7902 D1H8R0040009 RESISTOR NETWORKS 1 [PAVCSG]
R8007 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG] RX7903 D1H8R0040009 RESISTOR NETWORKS 1 [PAVCSG]
R8008 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG] RX7904 D1H8R0040009 RESISTOR NETWORKS 1 [PAVCSG]
R8009 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R8011 ERA3YKD104V M.RESISTOR 1/16W 100K 1 [PAVCSG]
R8012 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
R8013 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
R8014 ERJ2GEJ331X M.RESISTOR CH 1/16W 330 1 [PAVCSG]
R8015 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R8016 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R8017 ERJ2GEJ473X M.RESISTOR CH 1/16W 47K 1 [PAVCSG]
R8018 ERJ6GEYJ106V M.RESISTOR CH 1/10W 10M 1 [PAVCSG]
R8019 ERJ6GEYJ106V M.RESISTOR CH 1/10W 10M 1 [PAVCSG]
R8020 ERA3YED392V M.RESISTOR 1/16W 3.9K 1 [PAVCSG]
R8021 ERA3YED392V M.RESISTOR 1/16W 3.9K 1 [PAVCSG]
R8091 ERJ2GEJ223X M.RESISTOR CH 1/16W 22K 1 [PAVCSG]
R8092 ERJ2GEJ333X M.RESISTOR CH 1/16W 33K 1 [PAVCSG]
S8001 K0F111A00591 SWITCH 1 [PAVCSG]
S8002 K0F111A00591 SWITCH 1 [PAVCSG]
S8004 K0F212A00006 SWITCH 1 [PAVCSG]
VA8004 D4ED18R0A014 VARISTOR 1 [PAVCSG]
VA8005 D4ED18R0A014 VARISTOR 1 [PAVCSG]
VA8011 D4ED18R0A014 VARISTOR 1 [PAVCSG]
S-10
