DMC-GX1EG-S vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
92 VGQ1C68 GRIP FRONT TAPE [PAVCSG]
1 VEP56158B MAIN P.C.B. 1 (RTL) E.S.D. EG,EC,EF,EB 93 VGQ0Y08 LCD PCB SHEET [PAVCSG]
1 VEP56158A MAIN P.C.B. 1 (RTL) E.S.D. PP,PC,EE,GC, 99 VGQ1C77 INDUCTOR CUSHION 1 [PAVCSG]
GH,GT,GK,GN,GD 100 VGQ0T64-A FPC SHEET 1 [PAVCSG]
2 VGQ1C26 SHEET 1
3 VGQ0Y03 FPC SHEET 1 B1 VHD2331-A SCREW 1
4 VXQ2214 M-BOX UNIT 1 B2 VHD2331-A SCREW 1
5 VMC2111 SHOE SPRING 1 B3 VHD2331-A SCREW 1
30 VGK3823 GRIP PIECE FRONT 1 [PAVCSG] B4 VHD2198 SCREW 1
31 VGK3824 FRONT RING 1 [PAVCSG] B5 VHD2198 SCREW 1
32 VGU0J48 LENS RELEASE BUTTON 1 [PAVCSG] B6 VHD2198 SCREW 1
33 VMB4504 LENS RELEASE BUTTON SPRING 1 [PAVCSG] B7 VHD2102 SCREW 1 (-S)
34 VMP0A17 LENS RELEASE FIX PLATE 1 [PAVCSG] B7 VHD2103 SCREW 1 (-K)
35 VMP0A96 FRONT RING PLATE 1 [PAVCSG] B8 VHD2102 SCREW 1 (-S)
36 VYK5H56 FRONT CASE UNIT 1 (-S) [PAVCSG] B8 VHD2103 SCREW 1 (-K)
36 VYK5H55 FRONT CASE UNIT 1 (-K) [PAVCSG] B9 VHD2102 SCREW 1 (-S)
37 K0RC01100011 REAR OPERATION FPC 1 [PAVCSG] B9 VHD2103 SCREW 1 (-K)
38 VGK3825 GRIP PIECE REAR 1 [PAVCSG] B10 VHD2102 SCREW 1 (-S)
39 VGQ1A32 LCD FPC TAPE B 1 [PAVCSG] B10 VHD2103 SCREW 1 (-K)
40 VGQ1A32 LCD FPC TAPE B 1 [PAVCSG] B11 VHD2102 SCREW 1 (-S)
41 VMP0B01 REAR LCD PLATE 1 [PAVCSG] B11 VHD2103 SCREW 1 (-K)
42 VYK5H60 REAR CASE UNIT 1 (-S) [PAVCSG] B12 VHD2102 SCREW 1 (-S)
42 VYK5H58 REAR CASE UNIT 1 (-K) [PAVCSG] B12 VHD2103 SCREW 1 (-K)
43 VYK5H61 LCD UNIT 1 [PAVCSG] B13 VHD2102 SCREW 1 (-S)
51 VGQ0R70 CAPACITOR TAPE 1 [PAVCSG] B13 VHD2103 SCREW 1 (-K)
52 VMP0A98 TRIPOD 1 [PAVCSG] B14 VHD2102 SCREW 1 (-S)
53 VGQ0Y45 STRAP HOLDER 1 [PAVCSG] B14 VHD2103 SCREW 1 (-K)
54 VGU0H25 BATTERY LOCK KNOB 1 [PAVCSG] B15 VHD2102 SCREW 1 (-S)
55 VKF4966 JACK DOOR 1 (-S) [PAVCSG] B15 VHD2103 SCREW 1 (-K)
55 VKF4965 JACK DOOR 1 (-K) [PAVCSG] B16 VHD2102 SCREW 1 (-S)
56 VKM9654 BATTERY FRAME 1 [PAVCSG] B16 VHD2103 SCREW 1 (-K)
57 VMB4304 BATTERY LOCK SPRING 1 [PAVCSG] B17 VHD2102 SCREW 1 (-S)
58 VMB4516 BATTERY OUT SPRING 1 [PAVCSG] B17 VHD2103 SCREW 1 (-K)
59 VMB4543 BATTERY DOOR SPRING 1 [PAVCSG] B18 VHD2103 SCREW 1
60 VMP0A97 BATTERY CASE 1 [PAVCSG] B19 VHD2323 SCREW 1
61 VMP0A99 HEAT RADIATION PLATE 1 [PAVCSG] B20 VHD2323 SCREW 1
62 VMS8213 BATTERY DOOR SHAFT 1 [PAVCSG] B21 VHD2323 SCREW 1
63 VYF3468 BATTERY DOOR UNIT 1 (-S) [PAVCSG] B22 VHD2323 SCREW 1
63 VYF3467 BATTERY DOOR UNIT 1 (-K) [PAVCSG] B30 XQN16+BJ4FN SCREW 1 [PAVCSG]
64 ML-421S/DN BATTERY 1 [ENERGY] (B7901) B31 XQN16+BJ4FN SCREW 1 [PAVCSG]
65 VEP59109A EX LVF P.C.B. 1 (RTL) [PAVCSG] B32 XQN16+BJ4FN SCREW 1 [PAVCSG]
66 VMP0B02 SHOE PLATE 1 [PAVCSG] B39 XQN16+BJ4FN SCREW 1 [PAVCSG]
67 VWJ2321 MAIN-LVF FPC 1 [PAVCSG] B40 XQN16+BJ4FN SCREW 1 [PAVCSG]
68 VWJ2322 MAIN-TOP FPC 1 [PAVCSG] B41 VHD2198 SCREW 1 [PAVCSG]
69 K0RC01100012 REAR DIAL SWITCH UNIT 1 [PAVCSG] B42 VHD2286-A SCREW 1 [PAVCSG]
70 VEK0S34 MIC UNIT 1 [PAVCSG] B43 XQN16+BJ5FJK SCREW 1 [PAVCSG]
72 VGQ0Y46 MIC CUSHION (A) 1 [PAVCSG] B44 XQN16+BJ5FJK SCREW 1 [PAVCSG]
73 VGQ0Y47 MIC CUSHION (B) 1 [PAVCSG] B45 XQN16+BJ5FJK SCREW 1 [PAVCSG]
74 VGQ0Y48 MIC CUSHION (C) 1 [PAVCSG] B46 XQN16+BJ5FJK SCREW 1 [PAVCSG]
75 VYK5H70 TOP CASE UNIT 1 [PAVCSG] B47 XQN16+BJ5FJK SCREW 1 [PAVCSG]
75-1 VGK3848 MODE DIAL DECORATION 1 [PAVCSG] B48 VHD2198 SCREW 1 [PAVCSG]
75-2 VGU0K40 REC BUTTON 1 [PAVCSG] B49 VHD2168 SCREW 1 [PAVCSG]
75-3 VYK5G31 iA BUTTON 1 [PAVCSG] B50 VHD2286-A SCREW 1 [PAVCSG]
75-4 VGU0K42 POWER SWITCH 1 [PAVCSG] B51 VHD2198 SCREW 1 [PAVCSG]
75-5 VYK5J82 MODE DIAL BASE 1 [PAVCSG] B52 VHD1996 SCREW 1 [PAVCSG]
75-6 VYQ5979 SHUTTER BUTTON UNIT 1 [PAVCSG] B53 XQN16+BJ3FN SCREW 1 [PAVCSG]
75-7 VEK0S30 HOT SHOE UNIT 1 [PAVCSG] B54 VHD2380 SCREW 1 [PAVCSG]
75-8 VEP50100A TOP P.C.B. 1 (RTL) [PAVCSG] E.S.D. B55 VHD2380 SCREW 1 [PAVCSG]
76 L0AA01A00059 SPEAKER 1 [PAVCSG] B56 VHD2380 SCREW 1 [PAVCSG]
77 VEK0S31 CAPACITOR P.C.B. UNIT 1 [PAVCSG] (C7950) B57 VHD2380 SCREW 1 [PAVCSG]
79 VEP58171A FLASH P.C.B. 1 (RTL) [PAVCSG] E.S.D. B58 VHD2332 SCREW 1 [PAVCSG]
80 VGQ0Y45 STRAP HOLDER 1 [PAVCSG] B59 VHD2332 SCREW 1 [PAVCSG]
81 VGQ0Y55 FLASH HOLDER 1 [PAVCSG] B60 VHD2198 SCREW 1 [PAVCSG]
82 VGQ0Z89 SPEAKER CUSHION 1 [PAVCSG]
83 VMB4544 FLASH SPRING 1 [PAVCSG]
84 VMP0B00 SIDE PLATE (R) 1 [PAVCSG]
85 VMP0B13 FLASH STOPPER 1 [PAVCSG]
86 VWJ2323 MAIN-FLASH FPC 1 [PAVCSG]
87 VYQ7121 EARTH LINE 1 [PAVCSG]
88 VYQ7174 FLASH LOCK UNIT 1 [PAVCSG]
88-1 VGU0L01 FLASH LOCK KNOB 1 [PAVCSG]
88-2 VGQ0Y54 FLASH LOCK HOLDER 1 [PAVCSG]
88-3 VMB4440 FLASH LOCK SPRING 1 [PAVCSG]
89 EFN-AMDH2ZD FLASH UNIT 1 [PAVCSG]
90 VYQ7176 FLASH CASE UNIT 1 (-S) [PAVCSG]
90 VYQ7173 FLASH CASE UNIT 1 (-K) [PAVCSG]
91 VMS8137 FLASH SHAFT 1 [PAVCSG]
