1
Status indicator (P18)/
Wi-Fi
®
connection lamp
• The lamp lights green when the camera is
turned on, and lights blue when it is
connected to Wi-Fi.
2
Camera ON/OFF switch (P18)
3
[Fn] button (Fn1) (P25)
4
Motion picture button (P37)
5
Function button (Fn13) (P25)
6
Rear dial (P22)
7
Shutter button (P20)
8
Front dial (P22)
9
Self-timer indicator/
AF Assist Lamp
10
Function button (Fn7) (P25)
11
Exposure compensation dial (P27)
12
Mode dial (P21)
• Rotate the mode dial to switch the Recording
Mode.
13
Hot shoe (Hot shoe cover) (P13)
• Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
14
Stereo microphone
• Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
15
Focus distance reference mark
16
[REMOTE/MIC] socket
• An external microphone (optional) can
record higher quality audio than the built-in
microphone.
17
[AV OUT/DIGITAL] socket
18
[HDMI] socket
19
Shoulder strap eyelet (P14)
20
Speaker
• Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
21
Lens release button (P17)
22
Lens lock pin
23
Mount
24
Sensor
25
Lens fitting mark (P17)
