10 VQT5A24 (ENG)
Names and Functions of Main Parts
1 Camera [ON/OFF] button
2 Shutter button
3 Mode dial
4 Microphones
5 [Wi-Fi] antenna
6 Diopter adjustment dial
7 Strap eyelet
8 Control ring
9 NFC antenna
10 Lens barrel
11 Zoom lever
12 Flash
13 Self-timer indicator/
AF Assist Lamp
14 Lens
15 Viewfinder
16 LCD monitor
17 [LVF] button
• Use this to switch display
between viewfinder and LCD
monitor.
18 [Wi-Fi] button
19 Charging lamp/
Wi-Fi
®
connection lamp
20 [Fn] button
21 Playback button
22 Control dial
23 Cursor button
• In this manual, the button that
is to be used is indicated by
.
24 [MENU/SET] button
25 [DISP.] button
26
[Q.MENU/
] / [ ] button
27 Motion picture button
28 Strap eyelet
• We recommend using the
supplied hand strap to avoid
dropping the camera.
29 [HDMI] socket
30 [AV OUT/DIGITAL] socket
• This socket is also used when
charging the battery.
31 Tripod mount
• Do not attach to a tripod with
a 5.5 mm (0.22 inch) or longer
screw. Doing so may damage
this unit.
32 Speaker
33 Card/Battery door
34 Release lever
To Next Page
