Names and Functions of Main Parts
[MENU/SET]
Use this to display the menus, enter
the settings, etc. (→42)
Left cursor button ( )
• Self-timer (→60)
Down cursor button ( )
• Macro Mode etc. (→57)
Up cursor button ( )
• Exposure Compensation, Auto
Bracket etc. (→61)
Right cursor button ( )
• Flash (→54)
●
In this manual, the button that is used is indicated by .
20
Tripod Mount (→117)
Do not attach to a tripod with a
5.5 mm (0.22”) or longer screw.
Doing so may damage this unit.
21
Release lever (→15, 19)
22
Card/Battery door (→15, 19)
15 16
20
17
21
19
22
15
Microphone (→26, 34)
16
Mode dial (→25)
Use this to select the recording
mode.
17
Zoom lever (→51)
Operate this when zooming in on a
distant subject to record it larger.
18
Shutter button (→26, 28, 34)
Use this to focus and record still and
motion pictures.
19
Power button (→23, 25)
Use this to turn the camera on and
off.
18
