- 8 -
Before Use
14 Speaker
•
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
15 Lens barrel
16 Shoulder strap eyelet (P10)
17 Zoom lever (P48)
18 Shutter button (P27, 30)
19 Motion picture button (P33)
20 Camera [ON/OFF] button (P22)
21 Microphone
•
Be careful not to cover the microphone with
your finger.
22 Tripod mount
•
A tripod with a screw length of 5.5 mm
(0.22 inch) or more may damage this unit if
attached.
23 Card/Battery door (P12, 18)
24 Release lever (P12, 18)
25 [AV OUT/DIGITAL] socket (P13, 100, 103,
105)
•
This socket is also used when charging the
battery.
17
18
20
19
21
24
25
23
22
To Next Page
