- 9 -
Before Use
15 Lens barrel
16 [AV OUT/DIGITAL] socket (P13, 130, 133,
135)
•
This socket is also used when charging the
battery.
17 Strap eyelet (P24)
•
To prevent dropping, be sure to attach the
supplied strap and fit it to your wrist.
18 Zoom lever (P53)
19 Camera [ON/OFF] button (P22)
20 Shutter button (P26, 30)
21 Motion picture button (P33)
22 Tripod mount
•
It may not be possible to attach and securely
fasten a tripod with a screw length of 5.5 mm
(0.22 inch) or more to the camera. Doing so may
also damage the camera.
• It may not be possible to attach certain types of
tripods properly.
23 Card/Battery door (P12, 18)
24 Release lever (P12, 18)
15
16
17
23
24
22
To Next Page
