VQT4U14 (ENG)
4
-If you see this symbol-
∫ How to replace the Fuse
The location of the fuse differ according to the type of AC cable (figures A and B).
Confirm the AC cable fitted and follow the instructions below.
Illustrations may differ from actual AC cable.
1 Open the fuse cover with a
screwdriver.
2 Replace the fuse and
close or attach the fuse
cover.
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct
method of disposal.
Fuse cover
Figure A Figure B
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
DMC-FT5&TS5GH-VQT4U14_eng.book 4 ページ ２０１３年２月１３日 水曜日 午後１時１４分
