(ENG) VQT5E64 11
1 Flash
2 Self-timer indicator/
AF Assist Lamp
3 Control ring
4 Lens barrel
5 Lens
• Do not touch the lens barrier.
6 Viewfinder (LVF)
7 Diopter adjustment dial
• Adjusts the focus in the viewfinder.
8 [LVF] button
• Use this to switch display between
viewfinder and LCD monitor.
9 LCD Monitor
10 Charging lamp (Red)/
Wi-Fi
®
connection lamp (Blue)/
GPS status indicator (Green)
• The colour of the lamp differs
depending on the function.
11 Strap eyelet
• We recommend using the supplied
hand strap to avoid dropping the
camera.
12 [HDMI] socket
• Do not connect any other cables
except the HDMI micro cable. Doing
so may cause malfunction.
13 [AV OUT/DIGITAL] socket
• This socket is also used when
charging the battery.
14 Speaker
15 Microphones
16 Mode dial
• Use this to select the recording mode.
17 Shutter button
18 Zoom lever
19 Motion picture button
20 Camera [ON/OFF] button
21 Tripod mount
• Do not attach to a tripod with a
5.5 mm (0.22 inch) or longer screw.
Doing so may damage this unit.
• If you are not holding the camera,
for example when using self-timer
recording or remote recording, the
camera could tilt when the lens barrel
extends during zooming, so make
sure to secure the camera in place
with a tripod or by other means.
• It may not be possible to attach
certain types of tripods properly.
22 Card/Battery door
23 Release lever
24 [Wi-Fi] antenna
25 GPS antenna
26 NFC antenna
27 [Wi-Fi] button
28 Playback button
• Use this to select the recording mode
or playback mode.
29 [MENU/SET] button
30 [Q.MENU/ ] / [ ] button
• You can display the Quick Menu and
erase pictures.
31 [DISP.] button
• Use this to change display.
32 Control dial
• Turn the dial to select setting items
and change setting values.
33 [Fn] button
34 Cursor button
