Panasonic Lumix DMC-ZS15 User Manual

- 114 -
Viewing on TV screen
Viewing 3D still pictures
If you connect this camera to a 3D-capable TV, and play back still pictures that you
recorded in 3D, you can enjoy impressive 3D still pictures on the TV. If a 3D-capable TV
has an SD card slot, you can play back 3D still pictures that you recorded by inserting the
card into the slot.
For the latest information about devices that can play back 3D still pictures recorded with this
camera, please refer to the following support website.
http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.)
Preparation: Set [3D Playback] to [3D] (→47).
Connect the camera to a 3D-capable TV by use of an HDMI
mini cable (optional) to display the playback screen (→110)
Display still pictures recorded in 3D
• When the [VIERA Link] setting (→47) on the camera is set to [ON] and the camera
is connected to a VIERA Link (HDMI)-compatible Panasonic television (VIERA),
the television automatically switches its input and the playback screen is
displayed.
• [3D] appears on the thumbnail of the 3D still pictures.
■
To select and play back only still pictures recorded in 3D
Select [3D Play] in [Filtering Play] of the [Playback Mode] menu (→97)
■
To perform Slide Show playback of only still pictures recorded in 3D
Select [3D Play] in [Slide Show] of the [Playback Mode] menu (→95)
If you experience any ill effects, such as tiredness or sickness while viewing 3D-recorded
still pictures, switch the playback type to 2D.
■
The functions that are not operational or available for 3D still pictures:
• [Setup] menu
• [Playback] menu
• Playback Zoom
• Delete
■
To switch the playback method for the still pictures recorded in 3D
Select the picture recorded in 3D
Select [2D/3D Settings] on the [Playback Mode] menu and then press [MENU/SET]
• Playback method will switch to 3D if it is playing back in 2D (conventional image), or it
will switch to 2D if it is playing back in 3D.
• If you feel tired, uncomfortable or otherwise strange when playing back pictures
recorded in 3D, set to 2D.

Panasonic Lumix DMC-ZS15 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom	4 x
Optical zoom	16 x
Extra/Smart zoom	19.6 x
Focal length range	4.3 - 68.8 mm
Minimum aperture number	-
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	384 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 1EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.5 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	Mono
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Children, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB
Bluetooth	No

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	185 g
Weight (including battery)	208 g
