Panasonic Lumix DMC-ZS15 User Manual

- 12 -
Charging battery
Charging the battery
We recommend charging in a location where the ambient temperature is between 10 °C
and 30 °C (50 °F to 86 °F) (same for the battery temperature).
Set the camera ON/OFF switch to OFF
■
Charging the battery by connecting the camera to the electrical outlet
Connect the AC adaptor (supplied) and the camera using the USB connection cable
(supplied), and plug the AC adaptor (supplied) into the electrical outlet.
• Be sure to only use the AC adaptor indoors.
■
Charging the battery through the computer
Connect a computer to the camera using the USB connection cable (supplied).
●
It may not be possible to charge the battery from some computers depending on the
computer specifications.
●
If the computer enters hibernation mode during charging, charging may be stopped.
●
If a notebook computer that is not connected to an electrical outlet is connected to
the camera, the battery of the notebook computer will be depleted. Do not leave the
camera and notebook connected for a long period of time.
●
Always connect the USB connection cable to the USB connector on your computer.
Do not connect the USB connection cable to the USB connector of the monitor,
keyboard, printer, or USB hub.
USB connection cable (supplied)
• Always check the direction of the pins and
hold the plug straight to insert or remove it.
(If the cable is inserted in the wrong
direction, the pins could become deformed
and cause faulty operation.)
Align the marks ( to ) and
insert the plug.
Computer
Getting ready:
Turn on the computer.
AC adaptor
(supplied)
Charging lamp

Panasonic Lumix DMC-ZS15 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom	4 x
Optical zoom	16 x
Extra/Smart zoom	19.6 x
Focal length range	4.3 - 68.8 mm
Minimum aperture number	-
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	384 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 1EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.5 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	Mono
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Children, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB
Bluetooth	No

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	185 g
Weight (including battery)	208 g
