- 129 -
Message displays
[Memory card parameter error]
Card is not of SD standard.
When cards in capacities of 4 GB or more are used, only SDHC or SDXC Memory Cards are
supported.
[Read Error] / [Write Error] [Please check the card]
Data read has failed.
→ Check whether card has been inserted correctly (→15).
Data write has failed.
→ Turn off power and remove card, before re-inserting and turning on power again.
Card may possibly be damaged.
Try with a different card.
[Cannot record due to incompatible format(NTSC/PAL) data on this card.]
Format the card after saving necessary data on a PC etc. (→48)
Insert a different card.
[Motion recording was cancelled due to the limitation of the writing speed of the card]
If recording stops even when using a card of the recommended speed class (→16), the data writing
speed has dropped. If this happens, we recommend backing up the data on the memory card and
formatting it (→48).
Motion picture recording may be automatically terminated with certain cards.
[A folder cannot be created]
Folder numbers in use have reached 999.
Save needed data on a computer or other device, and then use [Format] on the camera. (→48)
Folder number is reset to 100 when performing [No.Reset] (→46).
[Picture is displayed for 16:9 TV] [Picture is displayed for 4:3 TV]
AV cable (optional) is connected to camera.
→ To remove message immediately → Press [MENU/SET].
→ To change aspect ratio → Change [TV Aspect] (→47).
USB connection cable (supplied) is only connected to camera.
→ Message disappears when cable is also connected to another device.
[This battery cannot be used]
Use a genuine Panasonic battery.
Battery cannot be recognized as terminal is dirty.
→ Wipe any dirt away from the battery terminal.
[Recording failed.]
Recording may be impossible if the recording location for a 3D image is too dark/too bright, or if the
subject lacks contrast.

Table of Contents

Other manuals for Panasonic Lumix DMC-ZS15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-ZS15 and is the answer not in the manual?

Panasonic Lumix DMC-ZS15 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels12.8 MP
Image sensor size1/2.3 \
Image formats supportedJPEG XR
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom4 x
Optical zoom16 x
Extra/Smart zoom19.6 x
Focal length range4.3 - 68.8 mm
Minimum aperture number-
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)384 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 1600, 3200, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 1EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.5 m
Flash range (wide)0.6 - 6.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC
Audio systemMono
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
USB version2.0
HDMI connector typeMini
Product colorBlack
Scene modesChildren, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth33.4 mm
Width104.9 mm
Height57.6 mm
Weight185 g
Weight (including battery)208 g
