- 136 -
Q&A Troubleshooting
Others
Menu not displayed in desired language.
Change [Language] setting (→49).
Camera rattles if shaken.
This sound is made by the lens movement and is not a fault.
Red lamp illuminated when pressing shutter button halfway in dark locations.
[AF Assist Lamp] is set to [ON] (→88).
AF Assist Lamp is not illuminated.
[AF Assist Lamp] is set to [OFF] (→88).
Not illuminated in bright locations.
Camera is hot.
Camera may become a little warm during use, but this does not affect performance or quality.
Lens makes a clicking noise.
When brightness changes, the lens may make a clicking noise and the monitor brightness may also
change, but this is due to aperture settings being made.
(Does not affect recording.)
Clock is incorrect.
Camera has been left for a long period.
→ Reset the clock (→19).
A long time was taken to set the clock (clock will be behind by the same lapse of time).
When using zoom, picture becomes slightly warped and the edges of the subject
become colored.
Pictures may be slightly warped or colored around the edges, depending on the zoom ratio, but this
is not a fault.
Zoom movement stops momentarily.
The zoom movement stops momentarily during Extended Optical Zoom operation, but this is not a
malfunction.
Zoom does not reach the maximum ratio.
If the zoom ratio stops at 3 x, [Macro Zoom] has been set. (→54)
File numbers are not recorded in sequence.
File numbers are reset when new folders are created (→120).
File numbers have jumped backwards.
Battery was removed/inserted with power on.
(Numbers may jump backwards if folder/file numbers are not correctly recorded.)
When no operation is performed for a while, the demo is suddenly displayed.
This is the Automatic Demo Mode that introduces the features of this camera.
Press [MENU/SET] to return to the previous screen.

Table of Contents

Other manuals for Panasonic Lumix DMC-ZS15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-ZS15 and is the answer not in the manual?

Panasonic Lumix DMC-ZS15 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels12.8 MP
Image sensor size1/2.3 \
Image formats supportedJPEG XR
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom4 x
Optical zoom16 x
Extra/Smart zoom19.6 x
Focal length range4.3 - 68.8 mm
Minimum aperture number-
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)384 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 1600, 3200, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 1EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.5 m
Flash range (wide)0.6 - 6.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC
Audio systemMono
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
USB version2.0
HDMI connector typeMini
Product colorBlack
Scene modesChildren, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth33.4 mm
Width104.9 mm
Height57.6 mm
Weight185 g
Weight (including battery)208 g
