- 62 -
Taking Pictures with different picture effects [Creative Control] mode
The flash is set to [Forced Flash Off].
A setting that was selected in [Creative Control] mode is retained even after the camera
is turned off.
Following [Rec] menu settings will be automatically adjusted and cannot be selected
manually.
[Sensitivity], [White Balance], [i.Exposure], [Min. Shtr Speed], [Color Mode]
Notes on the [Miniature Effect] setting
The recording screen is displayed with a slight delay when compared to usual
recording.
No audio is recorded for motion pictures.
When a motion picture is recorded, the finished recording will be approximately 1/10th
of the actual recorded time period. (If you record a motion picture for 10 minutes,
the resulting motion picture recording time will be approximately 1 minute.) The
recordable time displayed on the camera is approx. 10 times longer than actual time
needed for recording. When the recording mode is changed, be sure to check the
recordable time.
When you take a picture using a large picture size setting, the screen will become
dark for a certain period of time after the picture is taken. However, this occurs due to
signal processing and is not a defect.
Notes on the [Soft Focus] setting
The recording screen is displayed with a slight delay when compared to usual
recording. (When this effect is set, the recorded motion picture is played back like a
frame dropping.)
When you take a picture using a large picture size setting, the screen will become
dark for a certain period of time after the picture is taken. However, this occurs due to
signal processing and is not a defect.
Changing the selected picture effects ([Creative Control] menu)
Press [MENU/SET]
Use cursor button to select [Creative Control] menu and press [MENU/SET]
Press to select a setting, and then press [MENU/SET]
Recording motion pictures in
Records a motion picture at the optimum settings for the selected effects.

Table of Contents

Other manuals for Panasonic Lumix DMC-ZS15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-ZS15 and is the answer not in the manual?

Panasonic Lumix DMC-ZS15 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels12.8 MP
Image sensor size1/2.3 \
Image formats supportedJPEG XR
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom4 x
Optical zoom16 x
Extra/Smart zoom19.6 x
Focal length range4.3 - 68.8 mm
Minimum aperture number-
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)384 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 1600, 3200, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 1EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.5 m
Flash range (wide)0.6 - 6.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC
Audio systemMono
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
USB version2.0
HDMI connector typeMini
Product colorBlack
Scene modesChildren, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth33.4 mm
Width104.9 mm
Height57.6 mm
Weight185 g
Weight (including battery)208 g
