16
Problem Check here
Dust sensor lamp (red)
The lamp turns on
even when the dust
box is not full
● Thelampmayturnoninthefollowingcases,butthisisnormal. 
◦
Whensandordustissuckedupintensively→Cleanthedustbox. 
◦Whenrubbishisblockingtheextensionwandand/ornozzle
→Removetherubbish.
◦Whenusingthecrevicenozzle
The lamp does not
turn on even when
the dust box is full
● Thelampmaynotturnonwhentherearelargeamountsofpethairor
fluff,butthisisnormal.→Throwawaytherubbishinsidethedustbox.
● Thelampdoesnotturnonin“LONG”mode.→Checkin“HIGH”mode.
Noise
The operating noise
has become louder
The stick cleaner
makes a loud noise
● Filtersmaybeclogged.
● Rubbishmaybeblockingtheextensionwandand/ornozzle.
● Thenozzlemaybeobstructed.
If anomaly persists
even after checking
● Bringtheproduct(mainunit,extensionwand,dustingbrush,battery
andchargingadapter)alongwiththewarrantytoyourretailer.
Troubleshooting
(Continued)
Specications
Dimensions
(W×D×H)
(Stickcleaner)W55mm×D91mm×H1072mm
(Mainunit)W55mm×D59mm×H314mm
Weight
0.75kg(Stickcleaner)
0.53kg(Mainunitonly)
Operating noise 73dB(withdustingbrushandextensionwand)
Dust capacity 0.06L
Battery used
Rechargeablelithium-ionbattery
(ModelNo.AVV97V-TBH)
Rated voltage 10.8V
Rated capacity 1600mAh
Number of cells 3cells
Continuous
operating time
HIGH:Approx.7min.
LONG:Approx.30min.
(Fullycharged,newbattery/atambienttemperatureof20ºC)
(Charging adapter)
Charging power supply
Model No. AVV61V-TBH
Input
100-240V
50-60Hz0.2-0.1A
(Powerconsumption:Charging-Approx.6.2W,Removedfrommain
unit-Approx.0.5W)
Output 12V
0.5A
Charging time Approx.4hours.(Whenchargedfromatatambienttemperatureof20ºC)
Cord length
1.8m
Accessories
◦
Extensionwand(2)
◦ Floornozzle(1)
◦ Chargingadapter(1)
◦ Crevicenozzle(1)
◦ Strap(1)
◦ Dus tingbrush(1)
Nominal Specifications
Item Specifications Remark
ChargingCurrent 0.5A –
ChargingVoltage 12.18V –
Chargingcutcurrent 100mA –
Ambient(Charge) 0–45℃ –
Charge Limits
BatteryPackModel MaximumChargeCurrents,A MaximumChargeVoltage,V
AVV97V-TBH 0.525A 12.33V
Charging Information for battery pack
