27
TEMPERATURE RECORDER (OPTION)
Installation of temperature recorder
WARNING
Always disconnect the power supply to the unit prior to attachment of a temperature recorder
in
order to prevent electric shock or injury.
A temperature recorder is available for the biomedical freezer as the optional component. The type of
the temperature recorder is MTR-G85A, MTR-G85C and MTR-4015LH. For the attachment, the
recorder fixing is necessary.
Following shows the combination of recorder with the recorder fixing:
Temperature recorder Recorder fixing
MTR-4015LH (folding chart type) ----
MTR-G85A or MTR-G85C (circular chart type) MDF-S740T
Contact our sales representative or agent for the installation of a temperature recorder.
MTR-G85A or MTR-G85C
MDF-S740T
