32
SPECIFICATIONS
Product name
Biomedical Freezer
MDF-U334
External dimensions
W614 mm x D709 mm x
H1620 mm
Internal dimensions
W490 mm x D486 mm x
H1290 mm
Effective capacity 274 L
Exterior Painted steel
Interior Styrol resin
Insulation Rigid polyurethane foamed-in place
Outer door Painted steel
Lock 1
Caster 4
Leveling foot 2
Evaporator Tube on sheet type (also used as a shelf)
Access port
Diameter 30 mm
1 on left side
Condenser Wire and tube type
Compressor Hermetic type, 200 W
Refrigerant R-134a
Temperature controller Electronics controller (between -18
o
C and -35
o
C)
Temperature display Digital display (between -50
o
C and +50
o
C)
Temperature sensor Thermistor sensor
Temperature alarm Flash of digital indicator and alarm lamp, Buzzer, (Remote alarm)
Accessories
1 set of key, 1 scraper, 4 card holders,
4 large baskets
W446 mm x D369 mm x H220 mm
1 small basket
W487 mm x D221 mm x H155 mm
Weight
81
kg
Battery Nickel hydrogen battery, DC 6 V, 1100 mAh (5HR-AAC), Automatic charge
Optional component
Temperature recorder (MTR-4015LH)
Temperature recorder (MTR-G85A, MTR-G85C)
Recorder fixing for MTR-G85A, MTR-G85C (MDF-S740T)
Interface board (MTR-480, MTR-L03)
Data acquisition system (MTR-5000)
Note
:
Design or specifications will be subject to change without notice.
Refer to the updated catalog when ordering an optional component.
