Panasonic Mini DV - Replacement Parts List; Q1& Q2 Vcr Mechanism Section

7 REPLACEMENT PARTS LIST
7.1 Q1& Q2 VCR MECHANISM SECTION (1) PARTS LIST
Ref. No. Part No. Part Name & Description Remarks
601 VEG1495 CYLINDER U.
602 DFX25A7VWB CAPSTAN U.
603 VDG1284 DRIVE GEAR
604 VDG1285 CENTER GEAR
605 VDG1290 INTERFACE GEAR (C)
606 VDG1291 INTERFACE GEAR (D)
607 VDG1295 DECELERATION (A) NV-EX1,NV-DS77
607 VDG1330 DECELERATION (A) NV-DS99/990,NV-DS33,NV-EX3
608 VDG1296 DECELERATION (B) NV-EX1,NV-DS77
608 VDG1331 DECELERATION (B) NV-DS99/990,NV-DS33,NV-EX3
609 VDG1297 INTERFACE GEAR (A)
610 VDG1303-A INTERFACE GEAR (B)
612 VMA9908 PULLEY COVER
613 VMA9916 T4 GUIDE
614 VMA9917 TENSION PLATE
615 VMA0E52 GEAR COVER
616 VHD1430 CAPSTAN HOLDER NV-EX3
617 VMC1443 CYLINDER SPRING
618 L6DA8DKC0001 LOADING MOTOR U. NV-EX1,NV-DS77
619 VEM0679 LOADING MOTOR U. NV-DS99/990,NV-DS33,NV-EX3
620 VWJ1297 MECHANISM INTERFACE FLEX. NV-DS99/990,NV-DS33,NV-EX3
622 K0ZZ00000453 MODE SWITCH
623 VXA6124 S LOAD GEAR U.
624 VXA6125 T LOAD GEAR U.
625 VXA6133 PULLEY COVER
626 VXA6134 CHASSIS RADON U.
627 VXA6135 CAM GEAR U.
628 VXA6136 PINCH BEETLE
629 VXA6137 RELEASE BEETLE
630 VXA6138 RAIL U.
631 VXA6169 BOAT RADON U.
632 VXA6184 S3 BASE U.
