Oven Components Diagram
q External Air Vent
w Internal Air Vent
e Door Safety Lock System
r Exhaust Air Vent
t Control Panel
y Identification Plate
u Glass Tray
i Roller Ring
o Heat/Vapor Barrier Film
(do not remove)
aWaveguide Cover
(do not remove)
s Door Release Button
d Warning Label
f Time/Weight and Sensor Menu
Dial
g Menu Label
h Power Supply Cord
j Power Supply Plug
k Function Label
IP4927_39Y45CP_00_140417:IP3020_38X03CP_11_100514.qxd 2014-4-17 10:37 Page 11
orq ud a qw
j
th
f
g y s
i
e
e
k
d
Note
: The illustration is for reference only.
