Panasonic NA-127VB5WGB User Manual

NA-127VB5WGB / 127VB5WFR / 127VB5WES / 127VB5WTA / 127VB5WPL / 127VB5WGN / 127VB5WNR /
147VB5WDE / 147VB5WGB / 147VB5WGN / 147VB5WNR
16
9 Critical Torque Valuess
The bolts/nuts above are important for product safety purposes. Please tighten screw, bolts and nuts according to the torque values
given in table above.
Assembly Location Bolt/Nut Torque Min.
(Nm)
Torque Nom.
(Nm)
Torque Max.
(Nm)
Air Pressure
Wrench. (rpm)
* Transport Screw Assembly Transport Screws 6.50 6.50 7.00 1000
* Motor Assembly Motor Screws 6.00 6.50 7.50 800
*
Front Concrete Weight - Front
Tub Assembly
Front Counterweight Screws 14.00 14.50 14.75 600
* Upper Counter Weight Assembly Upper Counterweight Screws 25.00 27.50 30.00 440
*
Pulley - Drive Shaft - Washing
Group Assembly
Pulley - Drive Shaft Assembly
Bolt
39.50 40.00 40.50 440
* Heater Assembly Heater Assembly Nut 3.85 4.00 4.00 970

Panasonic NA-127VB5WGB Specifications

General

Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Door hinge	Left
Control type	Rotary
Display type	LCD
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Washing class	A
Drum capacity	7 kg
Maximum spin speed	1200 RPM
Number of washing programs	-

Weight and Dimensions

Depth	527 mm
Width	597 mm
Height	845 mm
Door diameter	330 mm
