To Next PageTo Next PageWhat to do if the Panasonic NA - 127VB6 is unable to drain?
If your Panasonic Washer is unable to drain, inspect the drain hose for clogs, immersion in water, extensions with joints, or freezing. Also, clean the drain filter if it is clogged.
What to do if the Panasonic NA - 127VB6 door is open?
If the door of your Panasonic Washer is open, ensure that it is closed properly.
What to do if the electricity supply cuts out while my Panasonic Washer is on?
If the electricity supply cuts out while your Panasonic Washer is on, the appliance will stop operating. When power is restored, it will resume operation from the point where it stopped.
What to do if a circuit breaker trips and the electricity supply is cut for Panasonic NA - 127VB6 Washer?
If a circuit breaker trips and the electricity supply is cut for your Panasonic Washer, the appliance will stop operating. When the breaker is reset, it will resume operation from the point where it stopped. It is recommended to determine the reason for the breaker tripping and take steps to resolve it.
What to do if the water supply is disrupted for Panasonic Washer?
If the water supply to your Panasonic Washer is disrupted, be aware that when the water supply returns, it may initially be impure. Disconnect the water supply hose and drain the impure water through the tap. Ensure the water supply hose is reconnected before using the appliance.
What to do if there is overflow in my Panasonic Washer?
If there is an overflow in your Panasonic Washer, check if the water supply valve or the water supply valve triac has failed. Switch off and unplug the appliance, shut off the tap, and contact your local Customer Service Centre.
Why is there an unusual noise or vibration in my Panasonic Washer?
An unusual noise or vibration in your Panasonic Washer could be due to metal items in the drum, the anchor bolts not being removed, or the appliance being on a sloping or unstable surface. If none of these are the cause, contact your local Customer Service Centre.
Why does the displayed remaining time change on my Panasonic NA - 127VB6 Washer?
The displayed remaining time on your Panasonic Washer changes because the time is estimated and corrected continually. Thus, the displayed time may vary.
Why is the display not clear on my Panasonic NA - 127VB6 Washer?
The display on your Panasonic Washer may not be clear if the appliance is in a brightly lit or sunlit area.
General| Door hinge | Left |
|---|---|
| Motor type | Brush |
| Drum volume | 50 L |
| Control type | Buttons, Rotary, Touch |
| Display type | LCD |
| Loading type | Front-load |
| Product color | White |
| Built-in display | Yes |
| Door opening angle | 140 ° |
| Appliance placement | Freestanding |
| Energy consumption washing per cycle | 0.83 kWh |
| Washing class | A |
| Annual water consumption washing | 9240 L |
| Annual energy consumption washing | 162 kWh |
| Half-load | - |
| Drum capacity | 7 kg |
| Cycle time (max) | 170 min |
| Delay start (max) | 24 h |
| Residual moisture | 53 % |
| Spin-drying class | B |
| Maximum spin speed | 1200 RPM |
| Noise level (spin) | 74 dB |
| Noise level (wash) | 58 dB |
Weight and Dimensions| Depth | 527 mm |
|---|---|
| Width | 597 mm |
| Height | 845 mm |
| Weight | 73000 g |
Safety instructions for children and general appliance use.
Precautions regarding the mains lead and plug.
Safety measures to prevent personal injury during operation.
Safety advice under 'Caution' regarding water and ignition sources.
Additional cautions for preventing injury, like door hinges and sliding hands.
Cautions against washing specific items or getting laundry caught.
Pre-operation checks for initial or prolonged non-use.
Procedure for first-time use to rinse the appliance.
Steps for sorting and preparing laundry for washing.
Instructions for adding detergent to the main compartment.
How to select a wash programme using the main dial.
Function of the button to start or pause a wash cycle.
Steps to set up and start a washing cycle.
Troubleshooting steps when buttons are unresponsive.
Troubleshooting steps when the appliance door cannot be opened.
Troubleshooting steps when water does not enter the appliance.
Troubleshooting for the 'Door is Open' error code.
Troubleshooting for the 'Unable to Supply Water' error code.
Troubleshooting for the 'Unable to Drain' error code.
Troubleshooting for the 'Overflow' error code.
Guidelines for selecting a suitable installation location.
Procedure for removing transport anchor bolts before installation.
Procedure for reinstalling anchor bolts for transport.
Steps to ensure the washing machine is level for stable operation.
Procedure for connecting the appliance to the electrical supply.
Details on connecting the water inlet hose.
Details on connecting and routing the water drain hose.
Step-by-step guide for attaching the water supply hose.
A comprehensive list to verify correct installation.
