Water supply hose
Caution
Do NOT connect the water supply -
hose to a combination tap.
Do NOT twist, squash, modify, or -
cut the hose.
Optimum mains water pressure is 0.1 - -
1.0 MPa. If the water pressure exceeds
this value, install a pressure reducing
valve.
Waterflow from the tap should be more -
than 5 L/min.
Connecting the water supply hose
Attach one end of the hose to 1.
the water inlet on the back of the
appliance and tighten the joint by
hand.
Attach the other end of the hose to 2.
the tap and tighten it the same way.
Standard hose -
Hose with water supply valve -
Open the tap slowly and make sure 3.
that there are no leaks around the
joints.
The joints are subject to water pressure.
Follow the instructions in this section to prevent water leaks. If you are unsure, ask a service
agent to connect the hoses.
Hoses and cable lengths
Left side connections Right side connections
