8. LOCATION OF PARTS AND REPLACEMENT PARTS
8.2.1 Replacement of Parts List - A
Model NA-F60A6
Ref.
No.
Part Name & Descriptic Part Number Safety TH MAL
SIN
(LOCAL)
IND
UAE
(ONE)
OMAN KUWAIT QATAR
UAE
(PGF)
SIN
(EXP)
PHIL
A 1
Panel A (Grey) AXW01307BR0J 1 1 1 1 1 1
Panel A (White) AXW01307BR0D 1 1 1 1 1
A 2 Panel Face B
AXW01467BU0J 1 (EXC.)
AXW01467BU5A 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.)
A 3
Body B (Grey) AXW01027BR0J 1 1 1 1 1 1
Body B (White) AXW01027BR0D 1 1 1 1 1
A 4 Lid Unit
AXW001G7BU0J
S
1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.)
AXW001G7BU0D 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.)
A 5 Lid packing A AXW01646UP00 4 4 4 4 4 4 4 4 4 4 4
A 6 Leveller AXW03536DKA0 1
A 7 Spinner Lid Label
AXW11177BS5D 1
AXW11177BS50 1 1 1 1 1 1 1 1 1 1
AXW11177BSKA 1 1 1
A 8 Feeding Port Packing AXW02676UP00 1 1 1 1 1 1 1 1 1 1 1
A 9 Controller Unit AXW024C7BU06 S 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.) 1 (EXC.)
A 10 Connector Lead Wire Unit AXW014A7BR00 1 1 1 1 1 1 1 1 1 1 1
A 11 Feeding Valve AXW292119706 S 1 1 1 1 1 1 1 1 1 1 1
A 12 Pressure Sensor U
AXW024T03200
S
1 1 1 1 1 1 1 1 1 1 1
AXW024T02900 1 1 1 1 1 1 1 1 1 1 1
A 13 Lid Hinge Shaft AXW01937BK00 1 1 1 1 1 1 1 1 1 1 1
A 14 Sub Drain Hose Unit AXW002Q6UP00 1 1 1 1 1 1 1 1 1 1 1
A 15 Detergent Case Unit AXW021B7BR00 1 1 1 1 1 1 1 1 1 1 1
A 16 Safety Switch
AXW166123400
S
1 1 1 1 1 1 1 1 1 1 1
AXW166122910 1 1 1 1 1 1 1 1 1 1 1
A 17 Lid Hinge Spring AXW11167BR00 1 1 1 1 1 1 1 1 1 1 1
A 18 Controller case lid AXW24277BR00 1 1 1 1 1 1 1 1 1 1 1
A 20 Panel Face C AXW01477BS00 1 1 1 1 1 1 1 1 1 1 1
No. Part Name Part Number Safety TH MAL SIN
(LOCAL)
IND UAE
(ONE)
OMAN KUWAIT QATAR UAE
(PGF)
SIN
(EXP)
PHIL
1 Special Tapping Screw XTWAXW469J 2 2 2 2 2 2 2 2 2 2 2
2
Binding Tapping Screw
XTB4+12CFJ 5 5 5 5 5 5 5 5 5 5 5
3 XTB4+15CFJ 2 2 2 2 2 2 2 2 2 2 2
4 XTB4+15CFJ 2 2 2 2 2 2 2 2 2 2 2
5 XTB4+15CFJ 2 2 2 2 2 2 2 2 2 2 2
6 XTB4+15CFJ 2 2 2 2 2 2 2 2 2 2 2
7 XTB4+15CFJ 2 2 2 2 2 2 2 2 2 2 2
SCREWS
