Panasonic NN-SD297 - Oven Component Identification; Visual Guide to Oven Parts

8
Oven Components Diagram
11
See-through Oven Window
22
Waveguide Cover (do not remove)
33
Oven Light (Oven Light can be replaced, see page 27)
44
Glass Tray (Turntable)
55
Oven Air Vent (Vent Grille is removable and can be cleaned,
see page 26)
66
Control Panel
77
Sensor Menu Dial
88
Time/Weight Dial
99
Door Release Button
00
Cooktop Light (Cooktop Light can be replaced, see page 27)
--
Grease Filter (Grease filter is removable and can be cleaned,
see page 27)
==
Shelf Supports
~~
Door Safety Lock System
!!
Identification Plate
@@
Warning Label
##
Function Label
$$
Menu Label
Shelf
Shelf can be used for 2-level cooking,
see page 20
Glass Tray
Roller Ring
