31
The serial number of this product may be found on the
left side of the control panel. You should note the model
number and the serial number of this oven in the space
provided and retain this book as a permanent record of
your purchase for future reference.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase ________________________
User’s Record
Power Source:
Power Consumption:
Cooking Power:*
Outside Dimensions
(H x W x D):
Oven Cavity Dimensions
(H x W x D):
Charcoal Filter (optional):
Operation Frequency:
Ventilation Power:
Noise Level:
Net Weight:
120 V, 60 Hz
1,490 W
1,100 W
418 mm x 759 mm x 381 mm
(16
7
/16" x 29
7
/8" x 15")
242 mm x 591 mm x 367 mm
(9
1
/2" x 23
1
/4" x 14
7
/16")
NN-CF203
2,450 MHz
Super Turbo High Low
420 CFM 300 CFM 160 CFM 130 CFM
60 dB 55 dB 49 dB 40 dB
Approx. 25.0 kg (55 lbs.)
*IEC Test procedure Specifications/part numbers subject to change without notice.
Specifications
