8.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00066V00HP CAUTION LABEL 1
2 F21559Y10QP OVEN STICKY PAPER 1
4 F10019Y00AP BASE 1
5 F10089W40HPS RUBBER FOOT 2
6 F10099Y00SAP CABINET BODY (U) 1 SD691S,ST671S
6 F10099Y00HAP CABINET BODY (U) 1 ST651W,ST641W
7 F200A9Y00SQP OVEN (U) 1 SD691S,ST671S,ST651W
7 F200A9Y10SQP OVEN (U) 1 ST641W
8 F20559Y00AP COVER 1
9 F21319Y00AP PULLY SHAFT 1
11 F290D6W50XP ROLLER RING (U) 1
12 F30209Y00AP DOOR HOOK 1
13 F11619Y00AP REINFORCEMENT BRACKET 1
17 F400A9Y00QP FAN MOTOR 1
18 F40089Y00AP FAN BLADE 1
19 F40259Y00AP AIR GUIDE A 1
20 F41449Y10QP ORIFICE 1
21 J607S4T00AP STEAM SENSOR 1 SD691S,ST671S,ST651W
22 F64499Y00AP SENSOR COVER A 1 SD691S,ST671S,ST651W
24 F64508660AP SENSOR COVER B 1 SD691S,ST671S,ST651W
25 F65439Y00AP SENSOR COVER C 1 SD691S,ST671S,ST651W
26 F61425U30XN MICRO SWITCH 1 (PRIMARY LATCH SWITCH)
27 F61415U30XN MICRO SWITCH 1 (SECONDARY LATCH SWITCH)
28 F61459V00XP THERMAL CUTOUT 1
29 F612E9C30BP INCANDESCENT LAMP (U) 1
30 F61785U30XN MICRO SWITCH 1 (SHORT SWITCH)
31 F606YBA00GP H.V.INVERTER (U) 1
32 2M261-M39R MAGNETRON 1
33 F62306V60BP FUSE 1
35 F66629Y00AP GROUNDING PLATE 1
36 F63266S30XP TURNTABLE MOTOR 1
37 F900C9Y10QP AC CORD W/PLUG 1
38 F607X9J20QP NOISE FILTER 1
40 F30069Y00AP HINGE A 1
41 XTWFL4+12T SCREW 2 FOR MAGNETRON
43 XTWFA4+12D SCREW 4 FOR CABINET BODY
44 XTWFA4+12LR SCREW 3 FOR HINGE A
45 F65859Y00AP INVERTER BRACKET 1
46 F03349Y40QP MENU LABEL 1 SD691S
28
NN-SD691S / NN-ST671S / NN-ST651W / NN-ST641W
