Panasonic NR-BY551VS

- 12 -
7. INVERTER CONTROL DISPLAY
NR-BY551 / NR-BY601
￭ Energy Saving
- Deodorizing function is less effective than normal mode.
- Frequent opening door raise the inner temperature.
When inner temperature become higher, the rotation of compressor automatically increase
on a temporary base and lowers inner temperature appropriately.
7.1 How to operate the “Energy Saving” mode
(NR-BY551 & NR-BY601)
ON
Press the button “Energy Saving”
(Blue light LED turns on)
Remarks
Inner temperature gets slightly higher than normal mode.
OFF
Press the button “Energy Saving” again and return to normal mode
(Blue light LED turns off)
￭ Quick Freezing
￭ Others
- If you want to stop the operation, press the button “Quick Freezing”.
- Blue light LED flashing means that the defrosting system is now working “Quick Freezing”
mode will start right after the defrosting operation is finished.
- Freezer temp. control does not operate during “Quick Freezing” mode.
(The compressor rotation is at the maximum level for “Quick Freezing” mode)
7.2 How to operate the “Quick Freezing” mode
(NR-BY551 & NR-BY601)
ON
Press the button “Quick Freezing”
(Blue light LED turns on)
Remarks
- As to the order of functions, “Quick Freezing” mode has priority over “Energy Saving” mode.
- When pressing the buttons of both “Quick Freezing” and “Energy Saving” at the same time
1. Blue light LED and blue light LED (”Quick Freezing” and “Energy Saving”) turns on.
2. After “Quick Freezing” mode for 150 min., is finished and its blue light LED turns off, “Energy Saving”
mode starts to operate.
3. Blue light LED of “Energy Saving” mode continues to turns on from the beginning until pressing its
button again to stop it.
- When pressing “Quick Freezing” button during “Energy Saving” mode, blue light LED turns on.
“Quick Freezing” mode starts to operate and “Energy Saving” mode stops.
150 MIN. “Quick Freezing” mode
OFF
The system will stop operating automatically when it runs for 150 min., and
return to normal mode. (Blue light LED turns off)
