A
B
C
D
E
F
G
H
1
2 3 4 5 6
4
CCD AND LENS SECTION
Lubrication Points
Lubrication Points
LUBRICATION POINTS
When the marked parts are replaced, apply the recommended lubricants
or adhesive for better maintenance of the unit.
Mark Kind of Lubricant
Grease Available from Factroy LSUQ0050
Availability Part Number
Note:
1. Parts with no Ref. No. in "EXPLODED VIEW" are not supplied.
And some Ref. No. will be skipped. Be sure to make your
orders of replacement parts according to the parts list.
2. The parts indicated by the dotted line are for Ass'y only
and are not supplied.
3. Disregard Ref. No. suffixes when ordering parts. They are used
to describe parts in "Disassembly/Assembly Procedures" section.
536
536
538
538
Solder
Solder
538
533
538
E50
64
63
61
66
65
62
(NV-GS6EE/GC,
NV-GS17EG/EF/E/EP/EB, NV-GS18E,
NV-GS21EG/EK/E/EP/EB,
NV-GS25GC/GN, NV-GS28GK)
(NV-GS35EG/E/EP/EB,
NV-GS35GC/GN,
NV-GS38GK)
42
NV-GS6EE / NV-GS6GC / NV-GS17E / NV-GS17EB / NV-GS17EF / NV-GS17EG / NV-GS17EP / NV-GS18E / NV-GS21E / NV-GS21EB / NV-GS21EG / NV-GS21EK / NV-GS21EP / NV-GS25GC / NV-GS25GN /
GS28GK / NV-GS35E / NV-GS35EB / NV-GS35EG / NV-GS35EP / NV-GS35GC / NV-GS35GN / NV-GS38GK
