Example1
Lay down on the table
Example2
Use ratchet type driver/wrench
Example3
Shift to the edge of the table
Example4
Insert objects that become step between unit and the table
How to remove the bottom screws
Shift
Table
Table
UP
74
Rear Cover Disassemble / Assemble -2
*) The product pictures and
drawing is for explanation.
It is not 2018 model.
M3x8
(Head Hexagon)
8mm
Bottom Screw Type
under
50mm
To Next Page
