S P E C F I L E
PT-LZ370
LCD Projector
As of December 2011
SFL11M020-2
5 / 1 1
Standard setting-up position
Upper edge of projected image
Lower edge of projected image
Projected image
L
L
HH
Projected image
L
230
(9-1/16)
65 (2-9/16)
H
70
(2-3/4)
62
(2-7/16)
∅49
(1-15/16)
∅43
(1-11/16)
Adjustable in
20 mm (25/32) steps
370.5–450.5
(14-19/32–17-3/4)
unit : mm (inch)
NOTE:
Illustrations show the projector installed
using optional ceiling mount bracket
ET-PKA110H.
This illustration is not drawn to scale.
1.02 m
1.27 m
1.52 m
1.78 m
2.03 m
2.29 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
1.1
1.4
1.7
2.0
2.3
2.6
2.9
3.5
4.3
5.8
7.3
8.7
2.3
2.9
3.5
4.1
4.7
5.2
5.8
7.0
8.7
11.6
14.6
17.5
-0.08
-0.09
-0.11
-0.13
-0.15
-0.17
-0.19
-0.22
-0.28
-0.37
-0.47
-0.56
0.58
0.71
0.86
1.00
1.15
1.29
1.44
1.71
2.15
2.86
3.58
4.30
–
–
–
–
–
–
–
–
–
–
–
–
40˝
50˝
60˝
70˝
80˝
90˝
100˝
120˝
150˝
200˝
250˝
300˝
/
/
/
/
/
/
/
/
/
/
/
/
(3.7)
(4.6)
(5.6)
(6.5)
(7.5)
(8.4)
(9.4)
(11.3)
(14.2)
(19.0)
(23.8)
(28.6)
(7.5)
(9.4)
(11.3)
(13.3)
(15.2)
(17.1)
(19.0)
(22.8)
(28.6)
(38.1)
(47.7)
(57.2)
(-0.26
(-0.30
(-0.36
(-0.43
(-0.49
(-0.56
(-0.62
(-0.72
(-0.92
(-1.21
(-1.54
(-1.84
1.90)
2.33)
2.82)
3.28)
3.77)
4.23)
4.72)
5.61)
7.05)
9.38)
11.75)
14.11)
–
–
–
–
–
–
–
–
–
–
–
–
Projection size
[diagonal]
Projection distance [L]
Min [wide] Max [telephoto]
P
Height from the edge of screen
to center of lens [H]
Projection distance for 16:9 aspect ratio screen
• The value for H (the height from the edge of the screen to the centre of the lens) is the value when the horizontal optical axis shift function is
not used. The value decreases when the horizontal optical axis shift function is used. For details, see Shift range on page 6.
• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.
• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.
C a u t i o n :
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop-
ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.
