Panasonic RN-190 - Specifications

Service Ma
ORDER NO. GAD8606582C1
nual
Micro Cassette
Micro cassette Recorder R N 1 90
RN-107 MECHANISM SERIES
@ SPECIFICATIONS
Power requirement:
Motor:
Power consumption:
Power output:
Tape speed:
Program time:
Fast forward and rewind time:
Track system:
Input:
Output:
Speaker:
Dimensions:
Weight:
(Black)
This is the Service Manual
for the following area.
[M]... For U.S.A.
AC; 120V, 60 Hz (with included Panasonic AC adaptor
RP-29XP
Battery; 3V (two “‘AA”’ size dry batteries)
Car battery; with optional Panasonic car adaptor RP-993 and
Panasonic DC plug adaptor RP-007
Electric governor motor
4W (with AC adaptor)
300mW RMS (Max.)
LP; '5/3. ips (1.2cm/s)
SP; '%/1, ips (2.4cm/s)
2 hours with RT-60MC microcassette tape (at LP)
1 hour with RT-60MC microcassette tape (at SP)
Approx. 120 seconds with RT-60MC microcassette tape
2-track monaural recording and playback
DC in; 3V (Mini type)
Monitor; 8Q (3.5)
1'/,” (38mm) PM dynamic speaker; 3Q
23/3” (W) X 4'/2”(H) X 11/46” (D)
(61 x 113.5 x 26.9) mm
6 oz (165g), without batteries
Weights and dimensions shown are approximate.
Design and specifications are subject to change without notice.
