Output
Phones 3.5 mm stereo (32 )
Dimensions (W x H x D) 460 x 168 x 268 mm
(18-1/8” x 6-5/8” x 10-9/
16”)
Weight About 3.2 kg without
batteries
Power consumption in
standby mode
1 W
Notes:
1. Weights and dimensions shown are approximate.
2. Design and specifications are subject to change without notice.
1
1. Before Repair and Adjustment
Disconnect AC power, discharge Power Supply Capacitors C120, C220, C317
through a 10 , 5 W resistor to ground. DO NOT SHORT-CIRCUIT DIRECTLY (with
a screw driver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid over
current.
Current consumption at AC 120 V, 60 Hz in NO SIGNAL mode should be ~75 mA
respectively.
2. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are
noticed:
- No sound is heard when the power is turned on.
3
To Next Page
