Panasonic RX-D10 - Page 47

Ref. No. Part No. Part Name & Description Remarks
148 RHD20049 AZIMUT SCREW [M]
149 RMA1080 HEAD PANEL [M]
151 RMR0149 HEAD BASE [M]
154 RXR0004 TAKE UP REEL ASSY [M]
155 RXR0005 SUPPLY REEL ASSY [M]
156 XTN2+6J BACK PLATE SCREW [M]
158 RHD26002 MOTOR SCREW [M]
159 XTN2+8F R/P SCREW [M]
160 RMG0102-1 MOTOR RUB. CUSHION [M]
162 RFM179ZA DC MOTOR ASS’Y [M]
163 RMA0108 MOTOR BK [M]
164 XTN26+8J MOTOR BK SCREW [M]
165 RME0098-2 E SLIDE LEVER SPRING [M]
166 RJR0033 EARTH LUG [M]
167 RML0080 ERASE HEAD ARM [M]
168 RSH1A006-U LEAF SWITCH [M]
16.2. Cabinet & CD Loading Mechanism
16.2.1. Cabinet & CD Loading Machanism Parts Location
16.2.2. Cabinet & CD Loading Machanism Parts List
