Ref. No. Part No. Part Name & Description Remarks
TRAVERSE DECK
358 RAE0152Z-1C TRAVERSE [M]
358-1 SHGD113-1 FLOATING CUSHION [M]
358-2 SNSD38 TRV MOTOR ASS’Y SCREW [M]
358-3 RAF0150A-1 OPTICAL PICKUP [M]
358-4 RDG0247 DRIVE GEAR [M]
358-5 RDG0248 INTERMEDIATE GEAR [M]
358-6 RXQ0339 TRAVERSE MOTOR ASS’Y [M]
358-7 RXQ0304-1 PLATE NUT ASS’Y [M]
358-8 XQN17+CG5 NUT PLATE ASS’Y SCREW [M]
358-9 XQS2+A3FZ SCREW [M]
358-10 XQS17+A35FZ SCREW [M]
359 RME0142 FLOATING SPRING A [M]
360 RME0109 FLOATING SPRING B [M]
361 RMR0698-K1 TRAVERSE CHASSIS [M]
362 RMS0627 FIXED PIN B [M]
363 XTN2+6G SCREW [M]
364 RMS0350 FIXED PIN A [M]
16.3. Components Parts List
Ref. No. Part No. Part Name & Description Remarks
P.C.B.
REP2880A-N CD SERVO P.C.B.
[M]RTL
REPX0196G MAIN(TUNER) P.C.B./PANEL(1) P.C.B./PANEL(2) P.C.B./SPEAKER
TERMINAL P.C.B./BATTERY P.C.B./POWER P.C.B.
[M]RTL
INTEGRATED CIRCUITS
IC1 TA2008AN IC TUNER [M]
IC2 LC72131D-U IC PLL [M]
IC302 S81252SGY-Z IC 5.2V REGULATOR
[M]
IC303 TA8227P IC POWER
[M]
IC501 S1NB20-4101 IC BRIDGE DIODE
[M]
IC701 AN8839NSBE2 IC RF HEAD AMP [M]
IC702 MN662790RSC IC LSI [M]
IC703 AN8739SBE2 IC 4CH DRIVER [M]
IC801 M38224M6H104 IC MICOM [M]
IC802 PST9123T IC RESET [M]
IC1001 BA3313L IC PRE AMP [M]
TRANSISTORS
Q1 KTC3199GRTA TRANSISTOR [M]
49
