Panasonic RX-D10 - Page 52

Ref. No. Part No. Part Name & Description Remarks
X2 RSXZ456KZ02 CERAMIC RESONATOR [M]
X3 RSXD7M20C01 CRYSTAL OSCILLATOR [M]
X701 RSXZ16M9M01T CERAMIC OSCILLATOR [M]
X802 RSXZ4M19Z01T MICON CRYSTAL [M]
FUSES
F501 XBA1C12NB5H FUSE
[M]
F502 XBA1C12NB5H FUSE
[M]
FUSE HOLDERS
FH501 RJF0028 FUSE HOLDER [M]
FH502 RJF0028 FUSE HOLDER [M]
FH503 RJF0028 FUSE HOLDER [M]
FH504 RJF0028 FUSE HOLDER [M]
FUSE PROTECTOR
FP301 ERD2FCVG220T 22 1/4W
[M]
JACKS
JK301 RJJ37TK09 JK HEADPHONE [M]
JK501 RJJ1SM02-X JK AC INLET (SW501)
[M]
WIRES
W301 REXX0218 TRANSFORMER TO MAIN [M]
W302 RWJ9003220SS MAIN TO SPEAKER WIRE [M]
W307 REXX0221 PANEL TO MAIN WIRE [M]
W401 RWJ9002080SS RANEL TO PANEL WIRE [M]
W501 RWJ8902170SS POWER TO BATT WIRE [M]
W502 REU08H240QS POWER TO BATT WIRE [M]
RESISTORS
R2 ERDS2TJ103T 10K 1/4W [M]
R3 ERDS2TJ332T 3.3K 1/4W [M]
R4 ERDS2TJ472T 4.7K 1/4W [M]
R5 ERDS2TJ221T 220 1/4W [M]
R6 ERDS2TJ104T 100K 1/4W [M]
R8 ERDS2TJ104T 100K 1/4W [M]
R9 ERDS2TJ104T 100K 1/4W [M]
R11 ERDS2TJ223T 22K 1/4W [M]
R12 ERDS2TJ103T 10K 1/4W [M]
R13 ERDS2TJ474T 470K 1/4W [M]
R14 ERDS2TJ474T 470K 1/4W [M]
R16 ERDS2TJ104T 100K 1/4W [M]
