TURN / TIME : A
mode in which a track mark is automatically added
every 5 minutes after recording from a few seconds ago.
: In this mode, record from TURN BACK a few seconds ago to prevent head breaks .
SL-J8 (Built-in phono equalizer) ¡ To connect
the SL-J8 to this unit, a pin mini code (sold separately: RP-
CAPM3G15) and a pin plug adapter (sold separately: RP-
PA66A) are required. Connect to the P-MD / AUX terminal of
this unit. ¡ To connect a player that does not have a built-in
phono equalizer to this unit, a phono equalizer (sold separately:
RFKZ0088KIT) that is treated as a service route is required. If
you connect it as it is, the sound will be reduced.
: Normal recording mode. The MANUAL track mark is not automatically added.
SYNCHRO : In
this mode, recording starts automatically
when playback of the connected device starts. Recording
pauses after about 3 seconds of silence, and resumes when
replay resumes. A track mark is automatically added to the
recording start position.
: Track mark appears every 5 minutes
TIME
MARK This
mode is automatically attached.
P-MD / AUX
General
portable MD
Cassette deck,
etc.
MANUAL? ÿ ÿ SYNCHRO? ÿ ÿ
TURN BACK? ÿ ÿ ÿ ÿ TURN /
TIME? ÿ ÿ TIME MARK?
RL
48
Use separately sold equipment The part numbers of the separately sold products are as of February 2003.
RP-CAM3G15, 1.5 m RP-CAPM3G15, 1.5 m
LINE OUT or
headphone output
Mini code (sold separately) Pin mini code (sold separately)
LINE OUT
Connect optional equipment
Press and hold as
needed to select input level
ÿ A player with a built-in phono equalizer
is required to connect an analog player .
Recommended product: Our analog player
MD
Check the recording level
When connected to the headphone jack of
an external device, play the external device
and adjust the volume of the external device
so that the level display occasionally lights
up to the end.
Select "AUX"
Recording mode The
recording mode that can be selected differs depending
on the connected device.
Record
on this unit
Press
3 Press
Connect with the power turned off.
ÿ Tilt and select "REC MODE"
ÿ Press [ENTER]
Record to MD from an optional device
RQT6953
is. Part numbers are subject to change.
ÿ Press [ENTER] ÿ
Tilt to select the recording mode (a left)
Level display
Four
2
1
P-MD: MD network compatible device
Remote control only
HIGH: When you want to raise the level (devices with
low signal level such as portable MD)
Remote control only
ÿ ÿ
Every time you press
ÿ ÿ
AUX: General external device
(MD network not supported)
NORMAL: When the level is not changed (device with
normal signal level)
time
turn
mark
back
turn
Synchro
time
manual
