174
2WAY (ME1 type)
Model Name U-8ME1E81 U-10ME1E81 U-12ME1E81 U-14ME1E81 U-16ME1E81
Power Source
380 / 400 / 415 V, 3N ～50 Hz
Cooling capacity
kW 22.4 28.0 33.5 40.0 45.0
BTU / h 76,500 95,600 114,300 136,500 153,600
Heating capacity
kW 25.0 31.5 37.5 45.0 50.0
BTU / h 85,300 107,500 128,000 153,600 170,600
Sound Pressure level dB(A) 56.5 59.0 61.0 62.0 62.0
Sound Power level dB(A) 71.0 73.5 75.5 76.5 76.5
Unit Dimensions
(H×W×D)
mm 758×770×930 1758×770×930 1758×770×930 1758×1000×930 1758×1000×930
Net weight
㎏
234 234 281 309 309
Model Name U-18ME1E81 U-20ME1E81
Power Source
380 / 400 / 415 V, 3N ～50 Hz
Cooling capacity
kW 50.0 56.0
BTU / h 170,600 191,100
Heating capacity
kW 56.0 63.0
BTU / h 191,100 215,000
Sound Pressure level dB(A) 60.0 63.0
Sound Power level dB(A) 74.5 77.5
Unit Dimensions
(H×W×D)
mm 1758×1540×930 1758×1540×930
Net weight
㎏
421 421
SPECIFICATIONS
13_F569612_Spec.fm Page 174 Wednesday, September 24, 2014 10:03 AM
