Mini VRF SYSTEM
Control Functions - Outdoor unit
1 - 36
1
12. Outdoor Unit Control PCB
1-2. Outdoor Unit HIC PCB
TD831186-00_欧州向け Mini VRF TD.indb 2 16/06/22 8:32:48
U-4LE2E8,U-5LE2E8,U-6LE2E8
LED2LED1
SW2
SW1
CN-HPS
RUN
TEST
CN-EXG
STOP
CN-TO
CN-SCG
CHK
CN-MOV1
CN-SILENT
CN-ROM
SA1
CN-OC
CN-EMG
CN-RC
CN-MOV4
CN-TERMINAL
CN-LPS
AP
MODE
A.ADD
DEF
SW4
SW3
CN-SCT
CN-EXL
CN-DISCH
JP001
U-4LE2E8, U-5LE2E8, U-6LE2E8
