Ref. No. Part No. Part Name & Description Remarks
CN803A RJU100W10 10P CONNECTOR [M]
CN803B RJT100W10 10P CONNECTOR [M]
CN901A K1MN27A00010 27P FFC CONNECTOR [M]
CN901B K1MN27A00010 27P FFC CONNECTOR [M]
CN1303 RJS1A5711 11P CONNECTOR [M]
CN1304 RJS1A5709 9P CONNECTOR [M]
CP800 REXX0230-1 2P MAIN TO CR120 [M]
CP1301 RJS1A6805-J CONNECTOR [M]
CP1902 K1KA09B00058 CONNECTOR [M]
CS971 RJU071H09M1 CONNECTOR [M]
COILS & TRANSFORMERS
L1 ELESNR68MA CHOKE COIL [M]
L2 ELESNR68MA CHOKE COIL [M]
L3 ELEXTR47MA9 CHOKE COIL [M]
L600 ELF15N035AN LINE FILTER
[M]
L801 G0C101JA0027 COIL [M]
L802 J0JKB0000020 EMI BEAD CORE [M]
L803 J0JKB0000020 EMI BEAD CORE [M]
L807 G0C101JA0027 COIL [M]
L900 G0C3R3JA0027 COIL [M]
L901 G0C3R3JA0027 COIL [M]
L1301 7L1A62N BIAS OCS COIL [M]
L1302 RLQB470JTD-D RF CHOKE COIL [M]
T600 G4C2AAJ00006 BACK UP TRANSFORMER
[M]
T601 G4C6ADH00001 POWER TRANSFORMER
[M]
COMPONENT COMBINATION
Z1 RLA2Z005-C AM COIL [M]
Z2 RL12Z021M-T COIL [M]
Z20 ENV17290G1Y FM TUNER PACK [M]
Z600 ERZV10V511CS ZENER
[M]
Z900 L5ACAFF00001 LCD DISPLAY [M]
Z901 B3RAB0000013 REMOTE SENSOR [M]
CERAMIC FILTERS
CF1 J0B1075A0086 CERAMIC CAPACITOR [M]
CF2 J0B1075A0077 CERAMIC FILTER [M]
RELAY
RL600 K6B1ADA00011 RELAY
[M]
WH504B RMR0314 CABLE HOLDER [M]
WH505A K1YF09000001 9P WIRE HOLDER [M]
WH800 RMR0318 9P WIRE HOLDER [M]
WH900 RMR0320 11P WIRE HOLDER [M]
