(*1) TPS operation (music search) detects the blank sections between music selections. Therefore, do not use tapes with the
following conditions:
·
A blank section that lasts only 4 seconds or less.
·
No blank sections (recording through microphones, etc.).
·
Music selections that have extremely low pitches or prolonged silent sections (such as classical music).
·
and/or Music recorded with fade in/out effect.
13.5.1. Error detection for CD Block
Error Code Abnormal Items Possible Cause
F15 CD REST SW abnormal CD traverse position intial setting operation failsafe counter (1000 ms) waiting for REST SW to
turn on. Error No. shall be clear by force or during coldstart.
H15 The CD tray closes CD disc tray detect switch NG. (Check and replace)
F26 CD servo LSI command
signal abnormal
CD function DTMS command, after system setting, If SENSE = ‘L’ cannot be detected.
Memory shall contain F26 code. After Power on, CD function shall continue, error shall occur
“NODISC”.
Error No. shall be clear by force or coldstart.
F28 DISC LOAD abnormal While going to play position, if failsafe counter is finished and switch o change or switch
target condition was not achieve, this error shall be memorized. Next time mechanism
operates, it shall do coldstart.
ErrorNo. shall be clear by force or coldstart.
F29 DISC unload abnormal While going to play position, if failsafe counter is finished and switch no change or switch
target condition was not achieve, this error shall be memorized. Next time mechanism
operates, it shall do coldstart.
ErrorNo. shall be clear by force or coldstart.
F27 Slide operation abnormal During vertical operation, if failsafe timer is finished and switch no change or switch target
condition was not achieve, this error shall be memorized. Next time mechanism operates, it
shall do coldstart.ErrorNo. shall be clear by force or coldstart.
F17 Down SW abnormal During vertical operation going to the bottom position, if failsafe timer is finished and switch
no change or switch target condition was not achieve, this error shall be memorized. The
Next time mechanism operates,it shall do mechanism initialization.Error No. shall be clear by
force or coldstart.
F22 Loading Mode / Mecha
abnormal
During mecha initialization, Loading mode mechanism abnormal, normal operation cannot be
achieve. The next time mechanism operates, it shall do mechanism initialization.Error No.
shall be clear by force or coldstart.
Abnormal item Error Display Method of detection
F75 CD power abnormal Under normal operation (self-diagnostic mode inclusive), check if CDRST is H for SELECTOR
at CD. If it is not H after 1 sec, it shall be memorised as an error.
13.5.2. Error detection code for Cassette Mechanism Block
Error Code Abnormal Items Possible Cause
H01 MODE SW abnormal Normal operation during mecha transition, MODE SW abnormal is memorised. The content
of abnormality can be confirmed in the abnormal detection mode explained in the later
section.
H02 REC INH SW abnormal
The content of abnormality can be confirmed in the abnormal detection mode explained in
the later section.
H03 HALF SW abnormal
F01 Reel pulse abnormal
F02 TPS abnormal
13.5.3. Doctor Mode set up
a) At any more (CD, TAPE, TUNER).
b) To enter Doctor Mode, press Doctor Mode key [C2DF] of special remote control or input 4 then 7 from the remote control while
pressing STOP n key of the main set.
13.5.4. Cold start setting
55
SA-PM29E / SA-PM29EB / SA-PM29EG
