6 Replacement Parts List
Notes :
·
Important safety notice :
When replacing any of these components, be sure to use
only manufacturer’s specified parts shown in the parts list.
·
[M] markings in the Remarks columns indicates parts
supplied by PAVCSG.
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 RFKHBPM54GNL SPEAKER CAB. ASS’Y L [M]
1 RFKHBPM54GNR SPEAKER CAB. ASS’Y R [M]
2 RYBV0048-K NET FRAME ASSY. [M]
3 RGKX0372-K PIEZZO ORNAMENT [M]
4 RGNV0299 SPEC LABEL [M]
5 RGPX0254-K FRONT PANEL (L) [M]
5 RGPX0255-K FRONT PANEL (R) [M]
6 RHD40019-S SCREW [M]
7 RKA0072-KJ LEG CUSHION [M]
8 RMG0520-K NET HOLDER [M]
9 RMQ1485 EVA PACKING (TWEETER [M]
10 RMQ1496 EVA PACKING (WOOFER) [M]
11 XTB4+16AFJK SCREW(STAND) [M]
CAPACITOR
C1 ECA1HAY4R7S 4.7uf 50V [M]
PACKING MATERIALS
P1 RPNV0097 POLYFOAM [M]
P2 RPF0271 MIRAMAT BAG [M]
SPEAKER
SP1 EAS10PL624A WOOFER [M]
SP2 EAS6PH129A TWEETER UNIT [M]
14
SB-PM54GN
FLE0702
