Panasonic SA-PM65MD - Electrical Parts List; INTEGRATED CIRCUITS; TRANSISTORS

Ref. No. Part No. Part Name & Description Remarks
P.C.B.
REP2895A-T MD SERVO P.C.B. SIDE-A/MD SERVO P.C.B. SIDE-B [M](RTL)
REP2807C CD SERVO P.C.B. [M](RTL)
REP2996B
RDS P.C.B./MAIN P.C.B./MD CONNECTOR P.C.B./MD LOADING
P.C.B./CD LOADING P.C.B.
[M](RTL)
RAN0005EM-2 TUNER PACK [M](RTL)
REP2997B TACT SWITCH P.C.B./PANEL P.C.B. [M](RTL)
REP2575A
MD SWITCH P.C.B.
[M](RTL)
REP2995B
POWER P.C.B./TRANSFORMER P.C.B.
[M]EG / (RTL)
REP2995C
POWER P.C.B./TRANSFORMER P.C.B.
[M]EB / (RTL)
INTEGRATED CIRCUITS
IC1 AN8772FHQ IC RF [M]
IC2 AN8814SB-E1 IC [M]
IC3 MN66616RA4 IC MSP LSI [M]
IC4 AK4518VF-E2 IC AD/DA [M]
IC5 RN5RG33AA-TL IC REGULATOR
[M]
IC6 TC7W04FTE12L IC [M]
IC9 RN5RZ26BA-TR IC REGULATOR
[M]
IC10 MN101D03DAA1 IC [M]
IC11 TC74HCT00AFL IC [M]
IC72 M51V4400D7FS IC 4M DRAM [M]
IC92 LB1830MS-TLM IC MOTOR DR [M]
IC201 LC72721NMTLM IC RDS [M]
IC401 BU4052BCF-E2 IC FUNCTION SW [M]
IC402 BH3857AFV-E2 IC SOUND PROCESSOR [M]
IC403 AN7135 IC POWER AMP [M]
IC404 AN7194K-LD IC BTC POWER [M]
IC471 BA4558FE2 IC OP AMP [M]
IC700 M9202-12BDR3 IC FL DRIVER [M]
IC701 AN8839NSBE2 IC HEAD AMP [M]
IC702 MN662790RSC IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC801 MN101C49KAA2 IC MICON [M]
IC802 TC74HCT7007A IC 3V TO 5V [M]
IC803 TC4050BF IC 5V T0 3V [M]
IC901 UPC29M33HF IC
[M]
IC903 BA6283N IC MOTOR DRIVER [M]
IC904 BA6283N IC MOTOR DRIVER [M]
TRANSISTORS
Q1 2SB1295-6-TB TRANSISTOR [M]
Q1 2SC1740SRTA TRANSISTOR [M]
Q2 2SD592ARTA TRANSISTOR
[M]
Q2 DTC114YETL TRANSISTOR [M]
Q3 2SB1462STX TRANSISTOR [M]
Q3 2SD592ARTA TRANSISTOR
[M]
Q5 2SB1295-6-TB TRANSISTOR [M]
Q6 DTC114YETL TRANSISTOR [M]
Q10 2SJ278MYTR TRANSISTOR [M]
