Panasonic SC-BTT460 - Amplifier Section; Speaker Section

52
VQT4Q15
* [BTT880] [BTT480] [BTT460] [BTT400]
The impedance of all the speakers is 3
≠.
[BTT300]
The impedance of speakers:
– Front speakers, Centre speaker, Surround speakers: 5 ≠
– Subwoofer: 3 ≠
SPEAKER SECTION
Woofer
CONE TYPE
(cm)
Full range
CONE TYPE
(cm)
Super
tweeter
Piezo type
[BTT880] [BTT480]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 20 jj
[BTT460]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 20 jj
[BTT400]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 16 jj
[BTT300]
Front j 6.5 j
Centre j 6.5 j
Surround j 6.5 j
Subwoofer 16 jj
Dimensions
(W (mm) k H (mm) k D (mm))
Mass
(Approx. kg)
[BTT880] [BTT480]
Front 270 k1185 k270 2.45
Centre 280 k86 k78 0.67
Surround 270 k1185 k270 2.45
Subwoofer 232 k406 k316 5.7
[BTT460]
Front 270 k1185 k270 2.45
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 232 k406 k316 5.7
[BTT400]
Front 80 k143 k75 0.48
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 145 k289.5 k258 3.0
[BTT300]
Front 80 k139 k70 0.37
Centre 146.5 k84 k78 0.5
Surround 80 k139 k70 0.37
Subwoofer 145 k289.5 k
259 3.0
AMPLIFIER SECTION
RMS TTL POWER
OUTPUT
[BTT880] [BTT480] [BTT460] [BTT400]
1000 W
[BTT300]
435 W
[BTT880] 1 kHz, 10 % total harmonic distortion
FRONT:
CENTRE:
185 W per ch (3 ≠)
180 W per ch (3 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER: 200 W per ch (3 ≠)
[BTT480] [BTT460]
[BTT400]
1 kHz, 10 % total harmonic distortion
FRONT:
CENTRE:
SURROUND:
160 W per ch (3 ≠)
160 W per ch (3 ≠)
160 W per ch (3 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER: 200 W per ch (3 ≠)
[BTT300] 1 kHz, 10 % total harmonic distortion
FRONT:
CENTRE:
SURROUND:
67 W per ch (5 ≠)
67 W per ch (5 ≠)
67 W per ch (5 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER: 100 W per ch (3 ≠)
Audio Input AUX k 1
Digital Audio Input Optical k 1
Sampling frequency:
32 kHz, 44.1 kHz, 48 kHz
Audio Format:
PCM, Dolby Digital, DTS
FM TUNER SECTION
Frequency range
87.50 MHz to 108.00 MHz
(50 kHz step)
Antenna terminals
75 ≠ (unbalanced)
TERMINAL SECTION
USB slot USB2.0
[BTT880] [BTT480] [BTT460] [BTT400]
2system
[BTT300]
1system
SD card slot
Connector
1 system
Ethernet 10BASE-T/100BASE-TX
1 system
[BTT880] Wireless LAN Standard Compliance:
IEEE802.11 b/g/n
Frequency range: 2.4 GHz
band
Security: WPA
TM
/WPA2
TM
(Encryption Type: TKIP/AES,
Authentication Type: PSK),
WEP (64 bit/128 bit)
