[BT T 560] [BTT460] Front speaker
Attach to a wall without the base and the stand.
≥ Reattaching the speaker cable to the stand
[BT T 500] Front speaker
[BT T 560] [BTT500] [BTT460] Surround speaker
[BT T 400] Front speaker, Surround speaker
Preventing tipping
[BT T 560] [BTT460] Front speaker
Preventing falling
Front speaker, Surround speaker, Centre speaker
1 Thread a string to the speaker.
≥ Use a string of less than ‰ 2.0 mm, which is
capable of supporting over 10 kg.
e.g., [B TT560] [BTT460] Front speaker
A String (not supplied)
B Rear of the speaker
2 Thread a string from the wall to the
speaker and tie tightly.
C Screw eye (not supplied)
D Wall or pillar
E Approx.150 mm
F Approx.120 mm
D 45 mm E 22 mm F 330 mm
G 45 mm H 25 mm
I 40 mm J 41 mm
Straighten the
cable and run
through the stand.
Pull out the cable
through the hole.
180 mm
To prevent tipping/falling of
the speakers
When mounted on a wall
When placed on the floor
