Panasonic SC-BTT560 - Specifications; General Unit Specifications; Speaker and Amplifier Specifications

52
VQT4Q16
Specifications
* The impedance of all the speakers is 3 ≠.
GENERAL
Power consumption [BTT560] [BTT500]
Approx. 89 W
[BTT460] [BTT400]
Approx. 80 W
Power consumption in
standby mode
Approx. 0.1 W
( [BTT56 0] [BTT50 0] When the other
connected devices are turned off)
Power supply AC 220 V to 240 V, 50 Hz
[BTT560] [BTT500]
iPod/iPhone Connector
DC OUT 5 V 1.0 A MAX
1 system
Dimensions (WkHkD) [BTT560]
460 mm k 40.0 mm k 279.3 mm
[BTT500]
460 mm k 38.7 mm k 279.3 mm
[BTT460] [BTT400]
460 mm k 47.7 mm k 265.4 mm
Mass [BTT560]
Approx. 3.0 kg
[BTT500]
Approx. 2.7 kg
[BTT460] [BTT400]
Approx. 2.4 kg
Operating temperature range 0 oC to 40 oC
Operating humidity range 35 % to 80 % RH (no condensation)
LASER Specification Class 1 LASER Product
Wave length: 790 nm (CDs)/
660 nm (DVDs)/405 nm (BDs)
Laser power: No hazardous
radiation is emitted with the
safety protection
AMPLIFIER SECTION
RMS TTL POWER
OUTPUT
1000 W
[BTT560] [BTT500] 1 kHz, 10 % total harmonic distortion
FRONT:
CENTRE:
SURROUND:
185 W per ch (3 ≠)
180 W per ch (3 ≠)
125 W per ch (3 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER: 200 W per ch (3 ≠)
[BTT460] [BTT400] 1 kHz, 10 % total harmonic distortion
FRONT:
CENTRE:
SURROUND:
160 W per ch (3 ≠)
160 W per ch (3 ≠)
160 W per ch (3 ≠)
100 Hz, 10 % total harmonic distortion
SUBWOOFER: 200 W per ch (3 ≠)
Audio Input AUX k 1
Digital Audio Input Optical k 1
Sampling frequency:
32 kHz, 44.1 kHz, 48 kHz
Audio Format:
PCM, Dolby Digital, DTS
SPEAKER SECTION
Woofer
CONE TYPE
(cm)
Full range
CONE TYPE
(cm)
Super
tweeter
Piezo type
[BTT560]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 16 jj
[BTT500]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 16 jj
[BTT460]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 16 jj
[BTT400]
Front j 6.5 ≤
Centre j 6.5 ≤
Surround j 6.5 ≤
Subwoofer 16 jj
Dimensions
(W (mm) k H (mm) k D (mm))
Mass
(Approx. kg)
[BTT560]
Front 270 k1185 k270 2.45
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 180 k408 k300 4.3
[BTT500]
Front 90 k223 k89 0.65
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 145 k289.5 k258 3.0
[BTT460]
Front 270 k1185 k270 2.45
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 145 k289.5 k258 3.0
[BTT400]
Front 80 k143 k75 0.48
Centre 280 k86 k78 0.67
Surround 80 k143 k75 0.48
Subwoofer 145 k289.5 k258 3.0
